(Unit : mm)
D8L60
600V 8A
Copyright & Copy;2000 Shindengen Electric Mfg.Co.Ltd
OUTLINE DIMENSIONS
RATINGS
SHINDENGEN
Case : ITO-220
High Voltage
trr70ns
Fully Isolated Molding
FEATURES
APPLICATION
PFC
Switching power supply
Free Wheel
CTV+B output, lighting
Absolute Maximum Ratings (If not specified Tc=25)
Item
Symbol
Conditions
Ratings
Unit
Storage Temperature
Tstg
-55150
Operating Junction Temperature
Tj
150
Maximum Reverse Voltage
V
RM
600
V
Average Rectified Forward Current
I
O
50Hz sine wave, R-load, Tc=106
8
A
Peak Surge Forward Current
I
FSM
50Hz sine wave, Non-repetitive 1 cycle peak value, Tj=25
170
A
Dielectric Strength
Vdis
Terminals to case, AC 1 minute
1.5
kV
Mounting Torque
TOR
(Recommended torque0.3Nm)
0.5
Nm
Electrical Characteristics (If not specified Tc=25)
Item
Symbol
Conditions
Ratings
Unit
Forward Voltage
V
F
I
F
=8A, Pulse measurement
Max.1.5
V
Reverse Current
I
R
V
R
=V
RM,
Pulse measurement
Max.25
A
Reverse Recovery Time
trr
I
F
=0.5A, I
R
=1A
Max.70
ns
Thermal Resistance
jc
junction to case
Max.3.5
/W
Super Fast Recovery Rectifiers
Single
0
t
p
I
O
T
D=t
p
/T
0
5
10
15
20
0
2
4
6
8
10
12
14
16
D8L60
0.3
Forward Power Dissipation
Tj = Tjmax
SIN
0.2
0.1
D=0.8
DC
0.5
0.05
Average Rectified Forward Current I
O
[A]
Forward Power Dissipation P
F
[W]
Peak Surge Forward Capability
0
50
100
150
200
250
300
350
1
10
100
D8L60
2
5
20
50
I
FSM
10ms 10ms
1 cycle
Number of Cycles [cycles]
Peak Surge Forward Current I
FSM
[A]
non-repetitive,
sine wave,
Tj=25
C before
surge current is applied
