Copyright & Copy;2000 Shindengen Electric Mfg.Co.Ltd
RATINGS
SHINDENGEN
OUTLINE DIMENSIONS
(Unit : mm)
SMD
TSS KL Series
KL3Z07
Case : 1F
Absolute Maximum Ratings
Item
Symbol
Conditions
Ratings
Unit
Storage Temperature
Tstg
-40125
Junction Temperature
Tj
125
Maximum Off-State Voltage
V
DRM
5
V
Surge On-State Current
I
TSM
10/1000s, Non-repetitive
30
A
8/20s, Non-repetitive
150
Electrical Characteristics (Tl=25)
Item
Symbol
Conditions
Ratings
Unit
Breakdown Voltage
V
BR
I
BR
= 1mA
Min 5.5
V
Off-State Current
I
DRM
V
D
= V
DRM
Max 10
A
Holding Current
I
H
Pulse measurement
Min 50
mA
On-State Voltage
V
T
I
T
= 2A
TYP 1.5
V
Junction Capacitance
Cj
f = 1kHz
Max 100
pF
OSC = 20mV, V
D
= 0V
Breakover Voltage - Junction Temperature
0.85
0.9
0.95
1
1.05
1.1
KL3Z07
-40
-20
0
20
40
60
80
100
120
0.05
0.5
0.2
20
50
5
2
200
500
2000
5000
0.02
0.05
0.5
0.2
20
5
2
0.005
0.002
TYP
Pulse test
Peak hold method
Junction Temperature Tj [
C]
Breakover Voltage Ratio V
BO
(T) / V
BO
(Tj=25
C)
