S30L60
600V 30A
Copyright & Copy;2000 Shindengen Electric Mfg.Co.Ltd
Case : MTO-3P
OUTLINE DIMENSIONS
(Unit : mm)
RATINGS
SHINDENGEN
Case : MTO-3P
High Voltage
trr150ns
Small jc
FEATURES
APPLICATION
PFC
Switching power supply
Free Wheel
Home Appliances, Office Equipment,
Factory Automation
Absolute Maximum Ratings (If not specified Tc=25)
Item
Symbol
Conditions
Ratings
Unit
Storage Temperature
Tstg
-55150
Operating Junction Temperature
Tj
150
Maximum Reverse Voltage
V
RM
600
V
Average Rectified Forward Current
I
O
50Hz sine wave, R-load, Tc=117
30
A
Peak Surge Forward Current
I
FSM
50Hz sine wave, Non-repetitive 1 cycle peak value, Tj=25
600
A
Mounting Torque
TOR
(Recommended torque
0.5Nm)
0.8
Nm
Electrical Characteristics (If not specified Tc=25)
Item
Symbol
Conditions
Ratings
Unit
Forward Voltage
V
F
I
F
=30A, Pulse measurement
Max.1.5
V
Reverse Current
I
R
V
R
=V
RM
, Pulse measurement
Max.25
A
Reverse Recovery Time
trr
I
F
=0.5A, I
R
=1A
Max.150
ns
Thermal Resistance
jc
junction to case
Max.0.7
/W
Super Fast Recovery Rectifiers
Single
0
t
p
I
O
T
D=t
p
/T
0
10
20
30
40
50
60
0
10
20
30
40
50
S30L60
0.3
Forward Power Dissipation
Tj = Tjmax
SIN
0.2
0.1
D=0.8
DC
0.5
0.05
Average Rectified Forward Current I
O
[A]
Forward Power Dissipation P
F
[W]
Peak Surge Forward Capability
0
200
400
600
800
1
10
100
S30L60
2
5
20
50
I
FSM
10ms 10ms
1 cycle
Number of Cycles [cycles]
Peak Surge Forward Current I
FSM
[A]
non-repetitive,
sine wave,
Tj=25
C before
surge current is applied
