VCO Product Specification
Model:
VCO191-926X
Rev: B
Date: 4/21/2003
Customer: VARI-L COMPANY
Operating Temperature Range:
( -35 to 85 C)
Parameter
Min
Typ
Max
Units
X
Remarks
Frequency Range -
913
926
939
MHz
X
Tuning Voltage:
913 MHz
0.4
1
Vdc
X
939 MHz
2.4
2.7
Vdc
X
Tuning Sensitivity -
15
20
23
MHz/V
X
Output Power -
-6
-3
0
dBm
X
Output Phase Noise:
10 kHz
-108
-102
dBc/Hz
100 kHz
-128
-122
dBc/Hz
X
Power Supply -
2.85
3
3.15
Volts
Supply Current -
7
9
mA
X
Harmonic Suppression:
2nd Harmonic
-15
-10
dBc
X
3rd Harmonic
-20
-10
dBc
X
Spurious (Non-Harmonic) -
-95
dBc
Frequency Pushing - 2.85-3.15 V
1
2
MHz p-p
Frequency Pulling - 12 dB RL
1
2
MHz p-p
Tuning Port Capacitance -
100
pF
Output Impedance -
50
Package Information
Package Type: X
Drawing Number: 60794
Dimensions: 9 x 7 x 1.72 mm
Drawing Revision: B
Comments
X Indicates parameter to be tested 100% in production
Page 1 of 1
