1/7
June 2001
s
HIGH SPEED: t
PD
= 4.1 ns (TYP.) at V
CC
= 5V
s
LOW POWER DISSIPATION:
I
CC
= 2
A (MAX.) at T
A
=25C
s
HIGH NOISE IMMUNITY:
V
NIH
= V
NIL
= 28% V
CC
(MIN.)
s
POWER DOWN PROTECTION ON INPUTS
s
SYMMETRICAL OUTPUT IMPEDANCE:
|I
OH
| = I
OL
= 8mA (MIN)
s
BALANCED PROPAGATION DELAYS:
t
PLH
t
PHL
s
OPERATING VOLTAGE RANGE:
V
CC
(OPR) = 2V to 5.5V
s
PIN AND FUNCTION COMPATIBLE WITH
74 SERIES 27
s
IMPROVED LATCH-UP IMMUNITY
DESCRIPTION
The 74VHC27 is an advanced high-speed CMOS
TRIPLE 3-INPUT NOR GATE fabricated with
sub-micron silicon gate and double-layer metal
wiring C
2
MOS technology.
The internal circuit is composed of 3 stages
including buffer output, which provides high noise
immunity and stable output.
Power down protection is provided on all inputs
and 0 to 7V can be accepted on inputs with no
regard to the supply voltage. This device can be
used to interface 5V to 3V.
All inputs and outputs are equipped with
protection circuits against static discharge, giving
them 2KV ESD immunity and transient excess
voltage.
74VHC27
TRIPLE 3-INPUT NOR GATE
PIN CONNECTION AND IEC LOGIC SYMBOLS
ORDER CODES
PACKAGE
TUBE
T & R
SOP
74VHC27M
74VHC27MTR
TSSOP
74VHC27TTR
TSSOP
SOP
74VHC27
2/7
INPUT EQUIVALENT CIRCUIT
PIN DESCRIPTION
TRUTH TABLE
X : Don`t Care
ABSOLUTE MAXIMUM RATINGS
Absolute Maximum Ratings are those values beyond which damage to the device may occur. Functional operation under these conditions is
not implied
RECOMMENDED OPERATING CONDITIONS
1) V
IN
from 30% to 70% of V
CC
PIN No
SYMBOL
NAME AND FUNCTION
1, 3, 9
1A to 3A
Data Inputs
2, 4, 10
1B to 3B
Data Inputs
13, 5, 11
1C to 3C
Data Inputs
12, 6, 8
1Y to 3Y
Data Outputs
7
GND
Ground (0V)
14
V
CC
Positive Supply Voltage
A
B
C
Y
L
L
L
H
H
X
X
L
X
H
X
L
X
X
H
L
Symbol
Parameter
Value
Unit
V
CC
Supply Voltage
-0.5 to +7.0
V
V
I
DC Input Voltage
-0.5 to +7.0
V
V
O
DC Output Voltage
-0.5 to V
CC
+ 0.5
V
I
IK
DC Input Diode Current
- 20
mA
I
OK
DC Output Diode Current
20
mA
I
O
DC Output Current
25
mA
I
CC
or I
GND
DC V
CC
or Ground Current
50
mA
T
stg
Storage Temperature
-65 to +150
C
T
L
Lead Temperature (10 sec)
300
C
Symbol
Parameter
Value
Unit
V
CC
Supply Voltage
2 to 5.5
V
V
I
Input Voltage
0 to 5.5
V
V
O
Output Voltage
0 to V
CC
V
T
op
Operating Temperature
-55 to 125
C
dt/dv
Input Rise and Fall Time (note 1) (V
CC
= 3.3
0.3V)
(V
CC
= 5.0
0.5V)
0 to 100
0 to 20
ns/V
74VHC27
3/7
DC SPECIFICATIONS
AC ELECTRICAL CHARACTERISTICS (Input t
r
= t
f
= 3ns)
(*) Voltage range is 3.3V
0.3V
(**) Voltage range is 5.0V
0.5V
CAPACITIVE CHARACTERISTICS
1) C
PD
is defined as the value of the IC's internal equivalent capacitance which is calculated from the operating current consumption without
load. (Refer to Test Circuit). Average operating current can be obtained by the following equation. I
CC(opr)
= C
PD
x V
CC
x f
IN
+ I
CC
/3 (per gate)
Symbol
Parameter
Test Condition
Value
Unit
V
CC
(V)
T
A
= 25C
-40 to 85C
-55 to 125C
Min.
Typ.
Max.
Min.
Max.
Min.
Max.
V
IH
High Level Input
Voltage
2.0
1.5
1.5
1.5
V
3.0 to
5.5
0.7V
CC
0.7V
CC
0.7V
CC
V
IL
Low Level Input
Voltage
2.0
0.5
0.5
0.5
V
3.0 to
5.5
0.3V
CC
0.3V
CC
0.3V
CC
V
OH
High Level Output
Voltage
2.0
I
O
=-50
A
1.9
2.0
1.9
1.9
V
3.0
I
O
=-50
A
2.9
3.0
2.9
2.9
4.5
I
O
=-50
A
4.4
4.5
4.4
4.4
3.0
I
O
=-4 mA
2.58
2.48
2.4
4.5
I
O
=-8 mA
3.94
3.8
3.7
V
OL
Low Level Output
Voltage
2.0
I
O
=50
A
0.0
0.1
0.1
0.1
V
3.0
I
O
=50
A
0.0
0.1
0.1
0.1
4.5
I
O
=50
A
0.0
0.1
0.1
0.1
3.0
I
O
=4 mA
0.36
0.44
0.55
4.5
I
O
=8 mA
0.36
0.44
0.55
I
I
Input Leakage
Current
0 to
5.5
V
I
= 5.5V or GND
0.1
1
1
A
I
CC
Quiescent Supply
Current
5.5
V
I
= V
CC
or GND
2
20
20
A
Symbol
Parameter
Test Condition
Value
Unit
V
CC
(V)
C
L
(pF)
T
A
= 25C
-40 to 85C
-55 to 125C
Min.
Typ.
Max.
Min.
Max.
Min.
Max.
t
PLH
t
PHL
Propagation Delay
Time
3.3
(*)
15
6.2
8.8
1.0
10.5
1.0
10.5
ns
3.3
(*)
50
8.7
12.3
1.0
14.0
1.0
14.0
5.0
(**)
15
4.1
5.9
1.0
7.0
1.0
7.0
5.0
(**)
50
5.6
7.9
1.0
9.0
1.0
9.0
Symbol
Parameter
Test Condition
Value
Unit
T
A
= 25C
-40 to 85C
-55 to 125C
Min.
Typ.
Max.
Min.
Max.
Min.
Max.
C
IN
Input Capacitance
6
10
10
10
pF
C
PD
Power Dissipation
Capacitance
(note 1)
17
pF
74VHC27
4/7
TEST CIRCUIT
C
L
=15/50pF or equivalent (includes jig and probe capacitance)
R
T
= Z
OUT
of pulse generator (typically 50
)
WAVEFORM: PROPAGATION DELAYS (f=1MHz; 50% duty cycle)
