1/11
June 2001
s
HIGH SPEED: t
PD
= 5.0 ns (TYP.) at V
CC
= 5V
s
LOW POWER DISSIPATION:
I
CC
= 4
A (MAX.) at T
A
=25C
s
HIGH NOISE IMMUNITY:
V
NIH
= V
NIL
= 28% V
CC
(MIN.)
s
POWER DOWN PROTECTION ON INPUTS
s
SYMMETRICAL OUTPUT IMPEDANCE:
|I
OH
| = I
OL
= 8 mA (MIN)
s
BALANCED PROPAGATION DELAYS:
t
PLH
t
PHL
s
OPERATING VOLTAGE RANGE:
V
CC
(OPR) = 2V to 5.5V
s
PIN AND FUNCTION COMPATIBLE WITH
74 SERIES 373
s
IMPROVED LATCH-UP IMMUNITY
s
LOW NOISE: V
OLP
= 0.9V (MAX.)
DESCRIPTION
The 74VHC373 is an advanced high-speed
CMOS OCTAL D-TYPE LATCH with 3 STATE
OUTPUTS NON INVERTING fabricated with
sub-micron silicon gate and double-layer metal
wiring C
2
MOS technology.
These 8 bit D-Type latch are controlled by a latch
enable input (LE) and an output enable input (OE).
While the LE inputs is held at a high level, the Q
outputs will follow the data input precisely . When
the LE is taken low, the Q outputs will be latched
precisely at the logic level of D input data. While
the (OE) input is low, the 8 outputs will be in a
normal logic state (high or low logic level) and
while (OE) is in high level, the outputs will be in a
high impedance state.
Power down protection is provided on all inputs
and 0 to 7V can be accepted on inputs with no
regard to the supply voltage. This device can be
used to interface 5V to 3V.
All inputs and outputs are equipped with
protection circuits against static discharge, giving
them 2KV ESD immunity and transient excess
voltage.
74VHC373
OCTAL D-TYPE LATCH
WITH 3 STATE OUTPUTS NON INVERTING
PIN CONNECTION AND IEC LOGIC SYMBOLS
ORDER CODES
PACKAGE
TUBE
T & R
SOP
74VHC373M
74VHC373MTR
TSSOP
74VHC373TTR
TSSOP
SOP
74VHC373
2/11
INPUT EQUIVALENT CIRCUIT
PIN DESCRIPTION
TRUTH TABLE
X : Don't Care
Z : High Impedance
* : Q Outputs are Latched at the time when the LE INPUT is taken low logic level
LOGIC DIAGRAM
This logic diagram has not be used to estimate propagation delays
PIN No
SYMBOL
NAME AND FUNCTION
1
OE
3 State Output Enable
Input (Active LOW)
2, 5, 6, 9, 12,
15, 16,19
D0 to D7
Data Inputs
3, 4, 7, 8, 13,
14, 17, 18
Q0 to Q7
3-State Outputs
11
LE
Latch Enable Input
10
GND
Ground (0V)
20
V
CC
Positive Supply Voltage
INPUTS
OUTPUT
OE
LE
D
Q
H
X
X
Z
L
L
X
NO CHANGE*
L
H
L
L
L
H
H
H
74VHC373
3/11
ABSOLUTE MAXIMUM RATINGS
Absolute Maximum Ratings are those values beyond which damage to the device may occur. Functional operation under these conditions is
not implied
RECOMMENDED OPERATING CONDITIONS
1) V
IN
from 30% to 70% of V
CC
Symbol
Parameter
Value
Unit
V
CC
Supply Voltage
-0.5 to +7.0
V
V
I
DC Input Voltage
-0.5 to +7.0
V
V
O
DC Output Voltage
-0.5 to V
CC
+ 0.5
V
I
IK
DC Input Diode Current
- 20
mA
I
OK
DC Output Diode Current
20
mA
I
O
DC Output Current
25
mA
I
CC
or I
GND
DC V
CC
or Ground Current
75
mA
T
stg
Storage Temperature
-65 to +150
C
T
L
Lead Temperature (10 sec)
300
C
Symbol
Parameter
Value
Unit
V
CC
Supply Voltage
2 to 5.5
V
V
I
Input Voltage
0 to 5.5
V
V
O
Output Voltage
0 to V
CC
V
T
op
Operating Temperature
-55 to 125
C
dt/dv
Input Rise and Fall Time (note 1) (V
CC
= 3.3
0.3V)
(V
CC
= 5.0
0.5V)
0 to 100
0 to 20
ns/V
74VHC373
4/11
DC SPECIFICATIONS
Symbol
Parameter
Test Condition
Value
Unit
V
CC
(V)
T
A
= 25C
-40 to 85C
-55 to 125C
Min.
Typ.
Max.
Min.
Max.
Min.
Max.
V
IH
High Level Input
Voltage
2.0
1.5
1.5
1.5
V
3.0 to
5.5
0.7V
CC
0.7V
CC
0.7V
CC
V
IL
Low Level Input
Voltage
2.0
0.5
0.5
0.5
V
3.0 to
5.5
0.3V
CC
0.3V
CC
0.3V
CC
V
OH
High Level Output
Voltage
2.0
I
O
=-50
A
1.9
2.0
1.9
1.9
V
3.0
I
O
=-50
A
2.9
3.0
2.9
2.9
4.5
I
O
=-50
A
4.4
4.5
4.4
4.4
3.0
I
O
=-4 mA
2.58
2.48
2.4
4.5
I
O
=-8 mA
3.94
3.8
3.7
V
OL
Low Level Output
Voltage
2.0
I
O
=50
A
0.0
0.1
0.1
0.1
V
3.0
I
O
=50
A
0.0
0.1
0.1
0.1
4.5
I
O
=50
A
0.0
0.1
0.1
0.1
3.0
I
O
=4 mA
0.36
0.44
0.55
4.5
I
O
=8 mA
0.36
0.44
0.55
Ioz
High Impedance
Output Leakage
Current
5.5
V
I
= V
IH
or V
IL
V
O
= V
CC
or GND
0.25
2.5
2.5
A
I
I
Input Leakage
Current
0 to
5.5
V
I
= 5.5V or GND
0.1
1
1
A
I
CC
Quiescent Supply
Current
5.5
V
I
= V
CC
or GND
4
40
40
A
74VHC373
5/11
AC ELECTRICAL CHARACTERISTICS (Input t
r
= t
f
= 3ns)
(*) Voltage range is 3.3V
0.3V
(**) Voltage range is 5.0V
0.5V
Note 1 : Parameter guaranteed by design. t
soLH
= |t
pLHm
- t
pLHn
|, t
soHL
= |t
pHLm
- t
pHLn
|
CAPACITIVE CHARACTERISTICS
1) C
PD
is defined as the value of the IC's internal equivalent capacitance which is calculated from the operating current consumption without
load. (Refer to Test Circuit). Average operating current can be obtained by the following equation. I
CC(opr)
= C
PD
x V
CC
x f
IN
+ I
CC
/8 (per Latch)
Symbol
Parameter
Test Condition
Value
Unit
V
CC
(V)
C
L
(pF)
T
A
= 25C
-40 to 85C
-55 to 125C
Min.
Typ.
Max.
Min.
Max.
Min.
Max.
t
PLH
t
PHL
Propagation Delay
Time
LE to Q
3.3
(*)
15
7.0
11.0
1.0
13.0
1.0
13.0
ns
3.3
(*)
50
9.5
14.5
1.0
16.5
1.0
16.5
5.0
(**)
15
4.9
7.2
1.0
8.5
1.0
8.5
5.0
(**)
50
6.4
9.2
1.0
10.5
1.0
10.5
t
PLH
t
PHL
Propagation Delay
Time
D to Q
3.3
(*)
15
7.3
11.4
1.0
13.5
1.0
13.5
ns
3.3
(*)
50
9.8
14.9
1.0
17.0
1.0
17.0
5.0
(**)
15
5.0
7.2
1.0
8.5
1.0
8.5
5.0
(**)
50
6.5
9.2
1.0
10.5
1.0
10.5
t
PZL
t
PZH
Output Enable
Time
3.3
(*)
15
R
L
= 1K
7.3
11.4
1.0
13.5
1.0
13.5
ns
3.3
(*)
50
R
L
= 1K
9.8
14.9
1.0
17.0
1.0
17.0
5.0
(**)
15
R
L
= 1K
5.5
8.1
1.0
9.5
1.0
9.5
ns
5.0
(**)
50
R
L
= 1K
7.0
10.1
1.0
11.5
1.0
11.5
t
PLZ
t
PHZ
Output Disable
Time
3.3
(*)
50
R
L
= 1K
9.5
13.2
1.0
15.0
1.0
15.0
ns
5.0
(**)
50
R
L
= 1K
6.5
9.2
1.0
10.5
1.0
10.5
t
w
Pulse Width (LE)
HIGH
3.3
(*)
5.0
5.0
5.0
ns
5.0
(**)
5.0
5.0
5.0
t
s
Setup Time D to LE
HIGH or LOW
3.3
(*)
4.0
4.0
4.0
ns
5.0
(**)
4.0
4.0
4.0
t
h
Setup Time D to LE
HIGH or LOW
3.3
(*)
1.0
1.0
1.0
ns
5.0
(**)
1.0
1.0
1.0
t
OSLH
t
OSHL
Output to Output
Skew time (note 1)
3.3
(*)
50
1.5
1.5
1.5
ns
5.0
(**)
50
1.0
1.0
1.0
Symbol
Parameter
Test Condition
Value
Unit
T
A
= 25C
-40 to 85C
-55 to 125C
Min.
Typ.
Max.
Min.
Max.
Min.
Max.
C
IN
Input Capacitance
7
10
10
10
pF
C
OUT
Output
Capacitance
9
pF
C
PD
Power Dissipation
Capacitance
(note 1)
15
pF
