BF3510TV
PRELIMINARY DATASHEET
August 1999 - Ed: 2A
FULL 50-60Hz RECTIFICATION BRIDGE
I
F(AV)
35 A
V
RRM
1000 V
Tj (max)
150 C
V
F
(max)
1.30 V
MAIN PRODUCT CHARACTERISTICS
COMPACT ISOTOP DESIGN COMPATIBLE
WITH FAST DIODES AND TRANSISTORS.
EXCELLENT THERMAL TRANSFER BETWEEN
JUNCTION AND HEATSINK
UL PENDING
FEATURES AND BENEFITS
The Bridges series from ST Microelectronics has
been designed to allow a better standardization of
packages on boards principally designed with ISO-
TOP packages. The insulated package of the
bridge will be able to sit on heatsink with other
components. Single phase and 3-phase high
power SMPS, UPS, MOTOR DRIVES and WELD-
ING equipment will primarily find advantage in
these industry package products.
DESCRIPTION
ISOTOP
TM
Symbol
Parameter
Value
Unit
V
RRM
Repetitive peak reverse voltage
1000
V
V
RSM
Non repetitive peak reverse voltage
1000
V
I
F(AV)
total
Average forward current
Tc = 80C sinusoidal
35
A
I
FSM
Surge non repetitive forward current
50Hz JEDEC method
300
A
I
2
.t
Fusing
660
A
2
.s
T
stg
Storage temperature range
- 55 to + 150
C
Tj
Maximum operating junction temperature
150
C
Pmax total
Totol power dissipation
50
W
ABSOLUTE RATINGS AND ELECTRICAL CHARACTERISTICS (per diode unless specified)
+
-
+
-
TM : ISOTOP is a trademark of ST Microelectronics.
1/3
Symbol
Parameter
Value
Unit
Rth (j-c)
Junction to case
total
0.5
C/W
THERMAL RESISTANCES
Symbol
Parameter
Test Conditions
Min.
Typ.
Max.
Unit
I
R
*
Reverse leakage
current
V
R
= 0.8 V
RRM
< 2%
tp = 5ms
T
j
= 25
C
10
A
T
j
= 125
C
0.2
mA
V
F **
Forward voltage
drop
I
F
= 35 A
< 2%
tp = 380
s
T
j
= 25
C
1.4
V
T
j
= 125
C
1.3
V
Pulse test : * tp = 5 ms, duty cycle < 2 %
** tp = 380
s, duty cycle < 2 %
For one diode: Pcond = 1.02 x I
F(AV)
+ 0.008 x I
2
F(RMS)
Tj = Pcond x 4 x R
th(j-c)
+ Tc
ELECTRICAL CHARACTERISTICS (Per diode)
STATIC CHARACTERISTICS
BF3510TV
2/3
PACKAGE MECHANICAL DATA
ISOTOP (Plastic)
REF.
DIMENSIONS
Millimeters
Inches
Min.
Max.
Min.
Max.
A
11.80
12.20
0.465
0.480
A1
8.90
9.10
0.350
0.358
B
7.8
8.20
0.307
0.323
C
0.75
0.85
0.030
0.033
C2
1.95
2.05
0.077
0.081
D
37.80
38.20
1.488
1.504
D1
31.50
31.70
1.240
1.248
E
25.15
25.50
0.990
1.004
E1
23.85
24.15
0.939
0.951
E2
24.80 typ.
0.976 typ.
G
14.90
15.10
0.587
0.594
G1
12.60
12.80
0.496
0.504
G2
3.50
4.30
0.138
0.169
F
4.10
4.30
0.161
0.169
F1
4.60
5.00
0.181
0.197
P
4.00
4.30
0.157
0.69
P1
4.00
4.40
0.157
0.173
S
30.10
30.30
1.185
1.193
Information furnished is believed to be accurate and reliable. However, STMicroelectronics assumes no responsibility for the consequences of
use of such information nor for any infringement of patents or other rights of third parties which may result from its use. No license is granted by
implication or otherwise under any patent or patent rights of STMicroelectronics. Specifications mentioned in this publication are subject to
change without notice. This publication supersedes and replaces all information previously supplied.
STMicroelectronics products are not authorized for use as critical components in life support devices or systems without express written ap-
proval of STMicroelectronics.
The ST logo is a registered trademark of STMicroelectronics
1999 STMicroelectronics - Printed in Italy - All rights reserved.
STMicroelectronics GROUP OF COMPANIES
Australia - Brazil - China - Finland - France - Germany - Hong Kong - India - Italy - Japan - Malaysia
Malta - Morocco - Singapore - Spain - Sweden - Switzerland - United Kingdom - U.S.A.
http://www.st.com
Ordering type
Marking
Package
Weight
Base qty
Delivery mode
BF3510TV
BF3510TV
ISOTOP
27g
without screws
10
Tube
Epoxy meets UL94,V0
Cooling method : by conduction (C)
Electrical isolation : 2500V
(RMS)
Capacitance : < 45 pF
Inductance : < 5 nH
- Recommended torque value : 1.3 N.m (MAX 1.5 N.m) for the 6 x M4 screws. (2 x M4 screws recommended for mounting the package on the
heatsink and the 4 screws given with the screw version).
- The screws supplied with the package are adapted for mounting on a board (or other types of terminals) with a thickness of 0.6 mm min and
2.2 mm max.
BF3510TV
3/3
