BFW43
HIGH VOLTAGE AMPLIFIER
DESCRIPTION
The BFW43 is a silicon planar epitaxial PNP
transistors in Jedec TO-18 metal case. It is
designed for use in amplifiers where high voltage
and high gain are necessary. In particular, its
feature a V
CEO
of 150V are specified over a wide
range of curent.
INTERNAL SCHEMATIC DIAGRAM
November 1997
ABSOLUTE MAXIMUM RATINGS
Symbol
Parameter
Value
Unit
V
CBO
Collect or-Base Voltage (I
E
= 0)
-150
V
V
CEO
Collect or-Emitt er Voltage (I
B
= 0)
-150
V
V
EBO
Emitt er-Base Voltage (I
C
= 0)
-6
V
I
C
Collect or Current
-0. 1
A
P
t ot
Total Dissipation at T
amb
25
o
C
at T
case
25
o
C
0.4
1.4
W
W
T
stg
St orage Temperature
-55 t o 200
o
C
T
j
Max. Operating Junction Temperature
200
o
C
TO-18
1/5
THERMAL DATA
R
t hj-ca se
R
t hj- amb
Thermal Resistance Junction-Case
Max
Thermal Resistance Junction-Ambient
Max
125
438
o
C/W
o
C/W
ELECTRICAL CHARACTERISTICS (T
case
= 25
o
C unless otherwise specified)
Symb ol
Parameter
Test Cond ition s
Mi n.
Typ .
Max.
Un it
I
CBO
Collect or Cut-off
Current (I
E
= 0)
V
CE
= -100 V
V
CE
= -100 V
T
a mb
= 125
o
C
-0. 2
-0.03
-10
-10
nA
A
V
( BR)CBO
Collect or-Base
Breakdown Volt age
(I
E
= 0)
I
C
= -10
A
-150
V
V
( BR)CEO
Collect or-Emitter
Breakdown Volt age
(I
B
= 0)
I
C
= -2 mA
-150
V
V
(BR)EBO
Emitt er-Base
Breakdown Volt age
(I
C
= 0)
I
E
= -10
A
-6
V
V
CE(sat )
Collect or-Emitter
Saturat ion Voltage
I
C
= -10 mA
I
B
= -1 mA
-0. 1
-0.5
V
V
BE(s at)
Base-Emitt er
Saturat ion Voltage
I
C
= -10 mA
I
B
= -1 mA
-0.74
-0.9
V
h
FE
DC Current G ain
I
C
= -1 mA
V
CE
= -10 V
I
C
= -10 mA
V
CE
= -10 V
I
C
= -10
A
V
CE
= -10 V
T
am b
= -55
o
C
40
40
85
100
30
f
T
Transit ion F requency
V
CE
= -10 V
f = 20 MHz
I
C
= -1 mA
I
C
= -10 mA
60
50
MHz
MHz
C
EBO
Emitt er Base
Capacitance
I
E
= 0
V
EB
= -0.5 V
f = 1MHz
20
25
pF
C
CBO
Collect or Base
Capacitance
I
E
= 0
V
CB
= -5 V
f = 1MHz
5
7
pF
Pulsed: Pulse duration = 300
s, duty cycle
1 %
DC Current Gain.
Collector-emitter Saturation Voltage.
BFW43
2/5
