1/5
ESDA6V1-4BC6
QUAD BIDIRECTIONAL TRANSIL
SUPPRESSOR FOR ESD PROTECTION
The
ESDA6V1-4BC6
is
a
monolithic
array
designed to protect up to 4 lines in a bidirectional
way against ESD transients.
The device is ideal for situations where board
space is at a premium.
DESCRIPTION
November 2002 - Ed: 1A
Where transient overvoltage protection in ESD
sensitive equipment is required, such as :
s
COMPUTERS
s
PRINTERS
s
COMMUNICATION SYSTEMS
s
VIDEO EQUIPMENT
This device is particularly adapted to the protection
of symmetrical signals.
APPLICATIONS
SOT23-6L (SC-74)
1
2
3
6
5
4
FUNCTIONAL DIAGRAM
SOT23-6L
Application Specific Discretes
A.S.D.TM
s
High ESD protection level
s
High integration
s
Suitable for high density boards
BENEFITS
- IEC61000-4-2: 15 kV (air discharge)
8 kV
(contact discharge)
- MIL STD 883E-Method 3015-7: class3
(human body model)
COMPLIES WITH THE FOLLOWING STANDARDS:
s
4 BIDIRECTIONAL TRANSIL FUNCTIONS
s
ESD PROTECTION FOR DATA, SIGNAL AND
V
CC
BUS
s
STAND OFF VOLTAGE RANGE: 5 V
s
LOW LEAKAGE CURRENT
s
PEAK PULSE POWER (8/20s); 80W
s
CHANNEL SEPARATION: 80dB typ.@20KHz
FEATURES
ESDA6V1-4BC6
2/5
With the focus of lowering the operation levels, the problem of malfunction caused by the environment is
critical. Electrostatic discharge (ESD) is a major cause of failure in electronic system.
Transient Voltage Suppressors are an ideal choice for ESD protection and have proven capable in
suppressing ESD events. They are capable of clamping the incoming transient to a low enough level such
that damage to the protected semiconductor is prevented.
Surface mount TVS arrays offer the best choice for minimal lead inductance.
They serve as parallel protection elements, connected between the signal line to ground. As the transient
rises above the operating voltage of the device, the TVS array becomes a low impedance path diverting the
transient current to ground.
1. ESD protection by ESDA6V1-4BC6
CONNECTOR
DRIVER
1
2
3
6
5
4
Bidirectional protection for 0V biased signals.
The ESDA6V1-4BC6 array is the ideal product for use as board level protection of ESD sensitive
semiconductor components.
The tiny SOT23-6L package allows design flexibility in the design of "crowded" boards where the space
saving is at a premium. This enables to shorten the routing and can contribute to improve ESD
performance.
2. Circuit Board Layout
Circuit board layout is a critical design step in the suppression of ESD induced transients. The following
guidelines are recommended :
s
The ESDA6V1-4BC6 should be placed as near as possible to the input terminals or connectors.
s
Minimise the path length between the ESD suppressor and the protected device
s
Minimise all conductive loops, including power and ground loops
s
The ESD transient return path to ground should be kept as short as possible.
s
Use ground planes whenever possible.
ESDA6V1-4BC6
3/5
Symbol
Test conditions
Value
Unit
V
PP
ESD discharge - MIL STD 883C - Method 3015-6
IEC61000-4-2 air discharge
IEC61000-4-2 contact discharge
25
15
8
kV
P
PP
Peak pulse power (8/20
s)
80
W
T
j
Junction temperature
150
C
T
stg
Storage temperature range
-55 to +150
C
T
L
Lead solder temperature (10 second duration)
260
C
T
op
Operating temperature range (note 1)
-40 to +125
C
Note 1: Variation of parameters is given by curves.
ABSOLUTE MAXIMUM RATINGS (T
amb
= 25C)
I
V
V
BR
CL
VRM
I PP
I RM
V
Rd
Type
V
BR
@
I
R
I
RM
@ V
RM
Rd
T
C
min.
max.
max.
typ.
max.
typ.
note 1
0V bias
V
V
mA
A
V
10
-4
/C
pF
ESDA6V1-4BC6
6.1
8
1
1
3
0.45
3
45
Note 1 : Square pulse, Ipp = 3A, tp=2.5
s.
Symbol
Parameter
V
RM
Stand-off voltage
V
BR
Breakdown voltage
V
CL
Clamping voltage
I
RM
Leakage current
I
PP
Peak pulse current
C
Capacitance
Rd
Dynamic resistance
ELECTRICAL CHARACTERISTICS (T
amb
= 25C)
0.0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
0
25
50
75
100
125
150
T (C)
j
P
[T initial] / P
[T initial=25C]
PP
j
PP
j
Fig. 1: Relative variation of peak pulse power
versus initial junction temperature.
10
100
1000
1
10
100
T
j
initial = 25C
t (s)
p
P
(W)
PP
Fig. 2: Peak pulse power versus exponential pulse
duration.
ESDA6V1-4BC6
4/5
0.1
1.0
10.0
100.0
0
5
10
15
20
25
30
35
40
45
50
V
(V)
CL
I
(A)
PP
t = 2.5s
T
p
j
initial = 25C
Fig. 3: Clamping voltage versus peak pulse
current (typical values, rectangular waveform).
0
5
10
15
20
25
30
35
40
45
50
0
1
2
3
4
5
6
V (V)
R
C(pF)
F = 1MHz
V
= 30mV
T
OSC
j
= 25C
Fig. 4: Junction capacitance versus line voltage
applied (typical values).
1
10
100
25
50
75
100
125
T (C)
j
I [T ] / I [T =25C]
R
j
R
j
Fig. 5: Relative variation of leakage current versus
junction temperature (typical values).
ESDA 6V1 4B C6
V
min.
BR
Bidirectional
ESD ARRAY
PACKAGE:
C6: SOT23-6L (SC-74)
ORDER CODE
50
I/O1
unloaded
GND
Port 1
V
G
Port 2
I/O6
50
Fig. 6: Analog crosstalk test configuration.
Symbol
Parameter
Conditions
(see note 2)
Values
Unit
Min.
Typ.
Max.
ch
Pin topic channel
separation
F = 20 KHz
80
dB
F = 10 MHz
34
Note 2 : According to figure 6 schematic.
ESDA6V1-4BC6
5/5
PACKAGE MECHANICAL DATA
SOT23-6L
mm
inch
3.50
0.138
0.60
0.024
1.20
0.047
1.10
0.043
0.95
0.037
2.30
0.090
FOOTPRINT
A2
A
L
H
b
E
D
e
e
A1
C
REF.
DIMENSIONS
Millimeters
Inches
Min.
Typ. Max.
Min.
Typ. Max.
A
0.90
1.45 0.035
0.057
A1
0
0.10
0
0.004
A2
0.90
1.30 0.035
0.0512
b
0.35
0.50 0.0137
0.02
c
0.09
0.20 0.004
0.008
D
2.80
3.00
0.11
0.118
E
1.50
1.75 0.059
0.0689
e
0.95
0.0374
H
2.60
3.00 0.102
0.118
L
0.10
0.60 0.004
0.024
10
10
Type
Marking
ESDA6V1-4BC6
BS77
Packaging: Standard packaging is tape and reel.
MARKING
