M27V101
1 Mbit (128Kb x 8) Low Voltage UV EPROM and OTP EPROM
s
LOW VOLTAGE READ OPERATION:
3V to 3.6V
s
FAST ACCESS TIME: 90ns
s
LOW POWER CONSUMPTION:
Active Current 15mA at 5MHz
Standby Current 20
A
s
PROGRAMMING VOLTAGE: 12.75V
0.25V
s
PROGRAMMING TIME: 100
s/byte (typical)
s
ELECTRONIC SIGNATURE
Manufacturer Code: 20h
Device Code: 05h
DESCRIPTION
The M27V101 is a low voltage 1 Mbit EPROM of-
fered in the two ranges UV (ultra violet erase) and
OTP (one time programmable). It is ideally suited
for microprocessor systems requiring large data or
program storage and is organized as 131,072 by 8
bits.
The M27V101 operates in the read mode with a
supply voltage as low as 3V. The decrease in op-
erating power allows either a reduction of the size
of the battery or an increase in the time between
battery recharges.
The FDIP32W (window ceramic frit-seal package)
has a transparent lid which allow the user to ex-
pose the chip to ultraviolet light to erase the bit pat-
tern.
Figure 1. Logic Diagram
AI00660B
17
A0-A16
P
Q0-Q7
VPP
VCC
M27V101
G
E
VSS
8
Table 1. Signal Names
A0-A16
Address Inputs
Q0-Q7
Data Outputs
E
Chip Enable
G
Output Enable
P
Program
V
PP
Program Supply
V
CC
Supply Voltage
V
SS
Ground
1
32
32
1
FDIP32W (F)
PDIP32 (B)
PLCC32 (K)
TSOP32 (N)
8 x 20 mm
M27V101
2/15
Figure 2B. LCC Pin Connections
Warning: NC = Not Connected.
AI00661
NC
A8
A10
Q5
17
A1
A0
Q0
Q1
Q2
Q3
Q4
A7
A4
A3
A2
A6
A5
9
P
A9
1
A16
A11
A13
A12
Q7
32
V
PP
V
CC
M27V101
A15
A14
Q6
G
E
25
V
SS
Figure 2A. DIP Pin Connections
Warning : NC = Not Connected.
A1
A0
Q0
A7
A4
A3
A2
A6
A5
A13
A10
A8
A9
Q7
A14
A11
G
E
Q5
Q1
Q2
Q3
VSS
Q4
Q6
NC
P
A16
A12
VPP
VCC
A15
AI01906
M27V101
8
1
2
3
4
5
6
7
9
10
11
12
13
14
15
16
32
31
30
29
28
27
26
25
24
23
22
21
20
19
18
17
A new pattern can then be written to the device by
following the programming procedure. For appli-
cations where the content is programmed only one
time and erasure is not required, the M27V101 is
offered in both PDIP32, PLCC32 and TSOP32 (8
x 20 mm) packages.
DEVICE OPERATION
The operating modes of the M27V101 are listed in
the Operating Modes table. A single power supply
is required in the read mode. All inputs are TTL
levels except for VPP and 12V on A9 for Electronic
Signature.
Read Mode
The M27V101 has two control functions, both of
which must be logically active in order to obtain
data at the outputs. Chip Enable (E) is the power
control and should be used for device selection.
Output Enable (G) is the output control and should
be used to gate data to the output pins, indepen-
dent of device selection. Assuming that the ad-
dresses are stable, the address access time
(t
AVQV
) is equal to the delay from E to output
(t
ELQV
). Data is available at the output after a delay
of t
GLQV
from the falling edge of G, assuming that
E has been low and the addresses have been sta-
ble for at least t
AVQV
-t
GLQV
.
Figure 2C. TSOP Pin Connections
Warning : NC = Not Connected.
A1
A0
Q0
A7
A4
A3
A2
A6
A5
A13
A10
A8
A9
Q7
A14
A11
G
E
Q5
Q1
Q2
Q3
Q4
Q6
NC
P
A16
A12
VPP
VCC
A15
AI01152B
M27V101
(Normal)
8
1
9
16
17
24
25
32
VSS
3/15
M27V101
Standby Mode
The M27V101 has a standby mode which reduces
the supply current from 15mA to 20
A with low
voltage operation V
CC
3.6V, see Read Mode DC
Characteristics table for details.The M27V101 is
placed in the standby mode by applying a CMOS
high signal to the E input. When in the standby
mode, the outputs are in a high impedance state,
independent of the G input.
Table 2. Absolute Maximum Ratings
(1)
Note: 1. Except for the rating "Operating Temperature Range", stresses above those listed in the Table "Absolute Maximum Ratings" may
cause permanent damage to the device. These are stress ratings only and operation of the device at these or any other conditions
above those indicated in the Operating sections of this specification is not implied. Exposure to Absolute Maximum Rating condi-
tions for extended periods may affect device reliability. Refer also to the STMicroelectronics SURE Program and other relevant qual-
ity documents.
2. Minimum DC voltage on Input or Output is 0.5V with possible undershoot to 2.0V for a period less than 20ns. Maximum DC
voltage on Output is V
CC
+0.5V with possible overshoot to V
CC
+2V for a period less than 20ns.
3. Depends on range.
Table 3. Operating Modes
Note: X = V
IH
or V
IL
, V
ID
= 12V
0.5V.
Table 4. Electronic Signature
Symbol
Parameter
Value
Unit
T
A
Ambient Operating Temperature
(3)
40 to 125
C
T
BIAS
Temperature Under Bias
50 to 125
C
T
STG
Storage Temperature
65 to 150
C
V
IO
(2)
Input or Output Voltage (except A9)
2 to 7
V
V
CC
Supply Voltage
2 to 7
V
V
A9
(2)
A9 Voltage
2 to 13.5
V
V
PP
Program Supply Voltage
2 to 14
V
Mode
E
G
P
A9
V
PP
Q0-Q7
Read
V
IL
V
IL
X
X
V
CC
or V
SS
Data Out
Output Disable
V
IL
V
IH
X
X
V
CC
or V
SS
Hi-Z
Program
V
IL
V
IH
V
IL
Pulse
X
V
PP
Data In
Verify
V
IL
V
IL
V
IH
X
V
PP
Data Out
Program Inhibit
V
IH
X
X
X
V
PP
Hi-Z
Standby
V
IH
X
X
X
V
CC
or V
SS
Hi-Z
Electronic Signature
V
IL
V
IL
V
IH
V
ID
V
CC
Codes
Identifier
A0
Q7
Q6
Q5
Q4
Q3
Q2
Q1
Q0
Hex Data
Manufacturer's Code
V
IL
0
0
1
0
0
0
0
0
20h
Device Code
V
IH
0
0
0
0
0
1
0
1
05h
M27V101
4/15
Two Line Output Control
Because EPROMs are usually used in larger
memory arrays, this product features a 2 line con-
trol function which accommodates the use of mul-
tiple memory connection. The two line control
function allows:
a. the lowest possible memory power dissipation,
b. complete assurance that output bus contention
will not occur.
For the most efficient use of these two control
lines, E should be decoded and used as the prima-
ry device selecting function, while G should be
made a common connection to all devices in the
array and connected to the READ line from the
system control bus. This ensures that all deselect-
ed memory devices are in their low power standby
mode and that the output pins are only active
when data is required from a particular memory
device.
System Considerations
The power switching characteristics of Advanced
CMOS EPROMs require careful decoupling of the
devices. The supply current, I
CC
, has three seg-
ments that are of interest to the system designer:
the standby current level, the active current level,
and transient current peaks that are produced by
the falling and rising edges of E. The magnitude of
the transient current peaks is dependent on the
capacitive and inductive loading of the device at
the output.
Table 5. AC Measurement Conditions
High Speed
Standard
Input Rise and Fall Times
10ns
20ns
Input Pulse Voltages
0 to 3V
0.4V to 2.4V
Input and Output Timing Ref. Voltages
1.5V
0.8V and 2V
Figure 3. AC Testing Input Output Waveform
AI01822
3V
High Speed
0V
1.5V
2.4V
Standard
0.4V
2.0V
0.8V
Figure 4. AC Testing Load Circuit
AI01823B
1.3V
OUT
CL
CL = 30pF for High Speed
CL = 100pF for Standard
CL includes JIG capacitance
3.3k
1N914
DEVICE
UNDER
TEST
Table 6. Capacitance
(1)
(T
A
= 25
C, f = 1 MHz)
Note: 1. Sampled only, not 100% tested.
Symbol
Parameter
Test Condit ion
Min
Max
Unit
C
IN
Input Capacitance
V
IN
= 0V
6
pF
C
OUT
Output Capacitance
V
OUT
= 0V
12
pF
5/15
M27V101
Table 7. Read Mode DC Characteristics
(1)
(TA = 0 to 70
C or 40 to 85
C; V
CC
= 3.3V
10%; V
PP
= V
CC
)
Note: 1. V
CC
must be applied simultaneously with or before V
PP
and removed simultaneously or after V
PP
.
2. Maximum DC voltage on Output is V
CC
+0.5V.
Table 8A. Read Mode AC Characteristics
(1)
(T
A
= 0 to 70
C or 40 to 85
; V
CC
= 3.3V
10%; V
PP
= V
CC
)
Note: 1. V
CC
must be applied simultaneously with or before V
PP
and removed simultaneously or after V
PP
.
2. Sampled only, not 100% tested.
3. Speed obtained with High Speed AC measurament conditions.
Symbol
Parameter
Test Condition
Min
Max
Unit
I
LI
Input Leakage Current
0V
V
IN
V
CC
10
A
I
LO
Output Leakage Current
0V
V
OUT
V
CC
10
A
I
CC
Supply Current
E = V
IL
, G = V
IL
, I
OUT
= 0mA,
f = 5MHz, V
CC
3.6V
15
mA
I
CC1
Supply Current (Standby) TTL
E = V
IH
1
mA
I
CC2
Supply Current (Standby) CMOS
E > V
CC
0.2V, V
CC
3.6V
20
A
I
PP
Program Current
V
PP
= V
CC
10
A
V
IL
Input Low Voltage
0.3
0.8
V
V
IH
(2)
Input High Voltage
2
V
CC
+ 1
V
V
OL
Output Low Voltage
I
OL
= 2.1mA
0.4
V
V
OH
Output High Voltage TTL
I
OH
= 400
A
2.4
V
Output High Voltage CMOS
I
OH
= 100
A
Vcc 0.7V
V
Symbol
Alt
Parameter
Test Condition
M27V101
Unit
- 90
(3)
-100
Min
Max
Min
Max
t
AVQV
t
ACC
Address Valid to Output Valid
E = V
IL
, G = V
IL
90
100
ns
t
ELQV
t
CE
Chip Enable Low to Output Valid
G = V
IL
90
100
ns
t
GLQV
t
OE
Output Enable Low to Output Valid
E = V
IL
45
50
ns
t
EHQZ
(2)
t
DF
Chip Enable High to Output Hi-Z
G = V
IL
0
30
0
30
ns
t
GHQZ
(2)
t
DF
Output Enable High to Output Hi-Z
E = V
IL
0
30
0
30
ns
t
AXQX
t
OH
Address Transition to Output
Transition
E = V
IL
, G = V
IL
0
0
ns
The associated transient voltage peaks can be
suppressed by complying with the two line output
control and by properly selected decoupling ca-
pacitors. It is recommended that a 0.1
F ceramic
capacitor be used on every device between V
CC
and V
SS
. This should be a high frequency capaci-
tor of low inherent inductance and should be
placed as close to the device as possible. In addi-
tion, a 4.7
F bulk electrolytic capacitor should be
used between V
CC
and V
SS
for every eight devic-
es. The bulk capacitor should be located near the
power supply connection point. The purpose of the
bulk capacitor is to overcome the voltage drop
caused by the inductive effects of PCB traces.
PDF
ZIP
