39
DC/DC CONVERTER TRANSFORMERS
DC/DC CONVERTER TRANSFORMERS
DC/DC CONVERTER TRANSFORMERS
12.0
4.0 4.0
4.0
4.0
6.0
21.0MAX.
23.0MAX.
0.8
17.5MAX.
Operating Freq. : Max. 300kHz
Max. Operating Power : 7.8W (100kHz)
18.0W (300kHz)
EI-22
21.0MAX.
21.0MAX.
28.0MAX.
15.5
5-4.5
4-5.5
0.8
3.0
Operating Freq. : Max. 300kHz
Max. Operating Power : 16.0W (100kHz)
38.0W (300kHz)
EI-255B
25.0MAX.
7.5
23.0MAX.
17.5
4-5.0
29.5MAX.
0.8
Operating Freq. : Max. 300kHz
Max. Operating Power : 22.0W (100kHz)
51.0W (300kHz)
EI-28
30.0
5-5.0
0.8
5.0
26.0MAX.
38.0MAX.
31.0MAX.
Operating Freq. : Max. 500kHz
Max. Operating Power : 11.0W (100kHz)
27.0W (300kHz)
40.0W (500kHz)
ERH2826
33.0MAX.
6.0
33.0MAX.
20.0
4-5.0
0.8
27.0MAX.
Operating Freq. : Max. 300kHz
Max. Operating Power : 29.0W (100kHz)
67.0W (300kHz)
EI-30
0.6
3.5
12- 2.54
17.5
26.0MAX.
35.0MAX.
31.0MAX.
25.0MAX.
1
17- 2.5
25.0
36-
0.6
3.5
33.0MAX.
49.0MAX.
33.0MAX.
Operating Freq. : Max. 500kHz
Max. operating power : 20W(500kHz)
Weight : 30g
Inductance : Max. 56mH
Operating Freq. : Max. 500kHz
Max. operating power : 60W(500kHz)
Weight : 75g
ER3023
ER4831
5-5.0
0.8
35.5MAX.
30.0MAX.
4.0
20.0MAX.
30.0
Operating Freq. : Max. 500kHz
Max. Operating Power : 10.0W (100kHz)
24.0W (300kHz)
36.0W (500kHz)
ERH2819
TYPE
DIMENSIONS(mm)
CONSTRUCTION
SPECIFICATIONS
