50 - 140 MHz
201 McLean Boulevard Paterson, New Jersey 07504 Tel: (973) 881-8800 Fax: (973) 881-8361
E-Mail: sales@synergymwave.com World Wide Web: http://www.synergymwave.com
Copyright 2005 Synergy Microwave Corporation
WIDE BANDWIDTH
VOLTAGE CONTROLLED OSCILLATOR
SURFACE MOUNT MODEL:
DCMO514-5
FEATURES:
Exceptional Phase Noise Performance
Small Size, Surface Mount
Lead Free REL-PRO
Technology
Phase Noise
-170
-160
-150
-140
-130
-120
-110
-100
-90
-80
-70
-60
-50
-40
-30
100
1000
10000
100000
1000000
10000000
Offset Frequency (Hz)
Phase Noise (dBc/Hz)
45.7MHz/0.5V
134MHz/17.47V
151.7MHz/25V
57MHz/2.09V
95.5MHz/8.31V
SPECIFICATIONS (Rev. A 02/20/06)
Frequency
50 - 140 MHz
Package #
278LF
Tuning Voltage (Full Band)
0.5 - 24 VDC
Bias Voltage
+5 VDC @ 30 mA (Max)
Output Power
+2 dBm (Min)
Tuning Sensitivity
6 MHz/V (Typ)
Output Impedance
50 Ohms (Nom)
Harmonic Suppression
10 dBc (Typ)
Frequency Pulling
3 MHz (Max @ 1.75:1 VSWR)
Frequency Pushing
1 MHz/V (Max)
Phase Noise @ 10 kHz
-105 dBc/Hz (Typ)
Operating Temperature Range
-40 to +85 C
Guaranteed Tuning Specifications
Tuning Voltage ( V )
Frequency ( MHz )
0.5
50 (Max)
5
65 (Min)
8
85 (Min)
12
100 (Min)
15
115 (Min)
18
130 (Min)
24
140 (Min)
50 - 140 MHz
201 McLean Boulevard Paterson, New Jersey 07504 Tel: (973) 881-8800 Fax: (973) 881-8361
E-Mail: sales@synergymwave.com World Wide Web: http://www.synergymwave.com
Copyright 2005 Synergy Microwave Corporation
WIDE BANDWIDTH
VOLTAGE CONTROLLED OSCILLATOR
SURFACE MOUNT MODEL:
DCMO514-5
P
E
R
F
O
R
M
A
N
C
E
P
L
O
T
S
40
60
80
100
120
140
160
0
5
10
15
20
25
Control Voltage (Vdc)
Frequency (MHz)
+25C
+85C
-40C
0
2
4
6
8
10
0
5
10
15
20
25
Control Voltage (Vdc)
Output Power (dBm)
+25C
+85C
-40C
50 - 140 MHz
201 McLean Boulevard Paterson, New Jersey 07504 Tel: (973) 881-8800 Fax: (973) 881-8361
E-Mail: sales@synergymwave.com World Wide Web: http://www.synergymwave.com
Copyright 2005 Synergy Microwave Corporation
WIDE BANDWIDTH
VOLTAGE CONTROLLED OSCILLATOR
SURFACE MOUNT MODEL:
DCMO514-5
P
E
R
F
O
R
M
A
N
C
E
P
L
O
T
S
0.00
2.00
4.00
6.00
8.00
10.00
0
5
10
15
20
25
Control Voltage (Vdc)
Tuning Sensitivity (MHz/V)
+25C
+85C
-40C
-20
-15
-10
-5
0
0
5
10
15
20
25
Control Voltage (Vdc)
2nd Harmonic Suppression
(dBc)
+25C
+85C
-40C
