INTELLIGENT INTERACTIVE SYNTHESIZER
2000 - 4000 MHz
WIDE BANDWIDTH
201 McLean Boulevard Paterson, New Jersey 07504 Tel: (973) 881-8800 Fax: (973) 881-8361
E-Mail: sales@synergymwave.com World Wide Web: http://www.synergymwave.com
Copyright 2005 Synergy Microwave Corporation
SURFACE MOUNT MODEL:
FSW200400-100
FEATURES:
Exceptionally Low Phase Noise
Interactive Communication
Standard Programming Interface
Ultra Wide Tuning Range
Lead Free - RoHS Compliant
Patent Pending REL-PRO
Technology
Small Size, Surface Mount
Phase Noise
-160
-150
-140
-130
-120
-110
-100
-90
-80
-70
-60
-50
-40
100
1000
10000
100000
1000000
10000000
Offset Frequency (Hz)
Phase Noise (dBc/Hz)
PN1 / 1900.01 MHz / 2.36 dBm
PN2 / 3000.02 MHz / 2.57 dBm
PN3 / 4100.03 MHz / 1.81 dBm
SPECIFICATIONS
Frequency
1900 - 4100 MHz
Package #
273LF
Package Style Surface Mount
Step Size
1000 kHz
Reference
Input Frequency
10 MHz
Reference
Input Voltage
1 V p-p to 3.3 V p-p
Bias Voltage
Vcc
V (Vdc)
I (mA Max)
Digital
+5
15
VCO
+5
50
Tune
+16
5
Output Power
+3 dBm 3 dB
Spurious Suppression
-70 dBc (Max)
Harmonic Suppression
-10 dBc (Typ)
Settling Time
10 mSec (Typ)
Output Impedance
50 Ohms
Typical Phase Noise
Offset
Phase Noise
@ 1 kHz
-85 dbc/Hz
@ 10 kHz
-85 dbc/Hz
@ 100 kHz
-110 dbc/Hz
Operating
Temperature Range
-40 to +85 C
Programming
See Application Note: AN7100
PIN-OUT
Pin 1 - Reset
Pin 2 - No Connection
Pin 3 - No Connection
Pin 4 - Error Flag
Pin 5 - Latch Enable In
Pin 6 - Ref In
Pin 7 - Vcc (Digital)
Pin 8 - Vcc (Tune)
Pin 9 - Vcc (VCO)
Pin 13 - RF Out
Pin 14 - Lock Detect Out
Pin 15 - Data In
Pin 16 - Clock In
All Others - Ground
INTELLIGENT INTERACTIVE SYNTHESIZER
2000 - 4000 MHz
WIDE BANDWIDTH
201 McLean Boulevard Paterson, New Jersey 07504 Tel: (973) 881-8800 Fax: (973) 881-8361
E-Mail: sales@synergymwave.com World Wide Web: http://www.synergymwave.com
Copyright 2005 Synergy Microwave Corporation
SURFACE MOUNT MODEL:
FSW200400-100
P
E
R
F
O
R
M
A
N
C
E
P
L
O
T
S
TYPICAL HARMONIC REJECTION
REFERENCE SIDEBAND SUPPRESSION
1 AP
CLRWR
A
Att 30 dB
*
RBW 1 kHz
VBW 100 Hz
SWT 30 s
*
Ref 2 dBm
Center 4.1 GHz
Span 3 MHz
300 kHz/
-100
-90
-80
-70
-60
-50
-40
-30
-20
-10
0
1
Marker 1 [T1 ]
0.73 dBm
4.100000000 GHz
1MHz Jump Fwd
Date: 27.OCT.2005 18:32:33
1 AP
CLRWR
A
Att 30 dB
*
RBW 3 MHz
VBW 30 kHz
SWT 170 ms
Ref 2 dBm
Start 0 Hz
Stop 15 GHz
1.5 GHz/
-100
-90
-80
-70
-60
-50
-40
-30
-20
-10
0
1
Marker 1 [T1 ]
1.25 dBm
4.086538462 GHz
2
Delta 2 [T1 ]
-26.96 dB
4.110576923 GHz
1MHz Jump Fwd
Date: 27.OCT.2005 18:46:36
INTELLIGENT INTERACTIVE SYNTHESIZER
2000 - 4000 MHz
WIDE BANDWIDTH
201 McLean Boulevard Paterson, New Jersey 07504 Tel: (973) 881-8800 Fax: (973) 881-8361
E-Mail: sales@synergymwave.com World Wide Web: http://www.synergymwave.com
Copyright 2005 Synergy Microwave Corporation
SURFACE MOUNT MODEL:
FSW200400-100
P
E
R
F
O
R
M
A
N
C
E
P
L
O
T
S
TYPICAL HARMONIC REJECTION
REFERENCE SIDEBAND SUPPRESSION
1 AP
CLRWR
A
Att 30 dB
Ref 3 dBm
300 kHz/
Center 1.9 GHz
Span 3 MHz
*
*
RBW 1 kHz
VBW 100 Hz
SWT 30 s
-100
-90
-80
-70
-60
-50
-40
-30
-20
-10
0
1
Marker 1 [T1 ]
1.93 dBm
1.900000000 GHz
2
Delta 2 [T1 ]
-83.06 dB
740.384615385 kHz
1MHz Jump Fwd
Date: 27.OCT.2005 18:41:54
1 AP
CLRWR
A
Att 30 dB
Ref 3 dBm
1.5 GHz/
Start 100 MHz
Stop 15.1 GHz
RBW 3 MHz
*
VBW 30 kHz
SWT 170 ms
-100
-90
-80
-70
-60
-50
-40
-30
-20
-10
0
1
Marker 1 [T1 ]
2.08 dBm
1.902884615 GHz
2
Delta 2 [T1 ]
-10.89 dB
1.899038462 GHz
1MHz Jump Fwd
Date: 27.OCT.2005 18:43:53
INTELLIGENT INTERACTIVE SYNTHESIZER
2000 - 4000 MHz
WIDE BANDWIDTH
201 McLean Boulevard Paterson, New Jersey 07504 Tel: (973) 881-8800 Fax: (973) 881-8361
E-Mail: sales@synergymwave.com World Wide Web: http://www.synergymwave.com
Copyright 2005 Synergy Microwave Corporation
SURFACE MOUNT MODEL:
FSW200400-100
P
E
R
F
O
R
M
A
N
C
E
P
L
O
T
S
TYPICAL HARMONIC REJECTION
REFERENCE SIDEBAND SUPPRESSION
1 AP
CLRWR
A
Att 30 dB
*
*
RBW 1 kHz
VBW 100 Hz
SWT 30 s
Ref 3 dBm
Center 3 GHz
Span 3 MHz
300 kHz/
-100
-90
-80
-70
-60
-50
-40
-30
-20
-10
0
1
Marker 1 [T1 ]
2.44 dBm
3.000000000 GHz
1MHz Jump Fwd
Date: 27.OCT.2005 18:39:09
1 AP
CLRWR
A
Att 30 dB
Ref 3 dBm
1.5 GHz/
Start 100 MHz
Stop 15.1 GHz
RBW 3 MHz
*
VBW 30 kHz
SWT 170 ms
-100
-90
-80
-70
-60
-50
-40
-30
-20
-10
0
1
Marker 1 [T1 ]
2.60 dBm
3.008653846 GHz
2
Delta 2 [T1 ]
-22.28 dB
2.980769231 GHz
1MHz Jump Fwd
Date: 27.OCT.2005 18:44:45
