120 - 230 MHz
OPTIMIZED BANDWIDTH
VOLTAGE CONTROLLED OSCILLATOR
SURFACE MOUNT MODEL:
MFC1223-12
FEATURES:
Low Phase Noise Performance
Fast Tuning
Ideal for PLL Applications
Small Size, Surface Mount
Lead Free REL-PRO
Technology
Phase Noise
-170
-160
-150
-140
-130
-120
-110
-100
-90
-80
-70
-60
-50
-40
-30
100
1000
10000
100000
1000000
10000000
Offset Frequency (Hz)
Phase Noise (dBc/Hz)
109.6MHz/0.5V
185MHz/8.18V
228.5MHz/18V
135MHz/2.42V
160.1MHz/5.08V
SPECIFICATIONS (Rev. A 03/13/06)
Frequency
120 - 230 MHz
Package #
278LF
Tuning Voltage (Full Band)
0.5 - 24 VDC
Bias Voltage
+12 VDC @ <35 mA
Output Power
+2 dBm (Min)
Tuning Sensitivity
4 - 12 MHz/V (Typ)
Output Impedance
50 Ohms (Nom)
Harmonic Suppression
10 dBc (Min)
Frequency Pulling
3 MHz (Typ @ 1.75:1 VSWR)
Frequency Pushing
2 MHz/V (Typ)
Phase Noise @ 10 kHz
-115 dBc/Hz (Typ)
Operating Temperature Range -40 to 85 C
Guaranteed Tuning Specifications
Tuning Voltage ( V )
Frequency ( MHz )
0.5
120 (Max)
5
140 (Min)
8
170 (Min)
12
195 (Min)
15
210 (Min)
18
220 (Min)
24
230 (Min)
201 McLean Boulevard Paterson, New Jersey 07504 Tel: (973) 881-8800 Fax: (973) 881-8361
E-Mail: sales@synergymwave.com World Wide Web: http://www.synergymwave.com
Copyright 2005 Synergy Microwave Corporation
120 - 230 MHz
OPTIMIZED BANDWIDTH
VOLTAGE CONTROLLED OSCILLATOR
SURFACE MOUNT MODEL:
MFC1223-12
P
E
R
F
O
R
M
A
N
C
E
P
L
O
T
S
0
1
2
3
4
5
6
0
5
10
15
20
25
Control Voltage (Vdc)
Output Power (dBm)
+25C
+85C
-40C
100
120
140
160
180
200
220
240
0
5
10
15
20
25
Control Voltage (Vdc)
Frequency (MHz)
+25C
+85C
-40C
201 McLean Boulevard Paterson, New Jersey 07504 Tel: (973) 881-8800 Fax: (973) 881-8361
E-Mail: sales@synergymwave.com World Wide Web: http://www.synergymwave.com
Copyright 2005 Synergy Microwave Corporation
120 - 230 MHz
OPTIMIZED BANDWIDTH
VOLTAGE CONTROLLED OSCILLATOR
SURFACE MOUNT MODEL:
MFC1223-12
P
E
R
F
O
R
M
A
N
C
E
P
L
O
T
S
0.00
2.00
4.00
6.00
8.00
10.00
12.00
14.00
16.00
0
5
10
15
20
25
Control Voltage (Vdc)
Tuning Sensitivity (MHz/V)
+25C
+85C
-40C
-50
-40
-30
-20
-10
0
0
5
10
15
20
25
Control Voltage (Vdc)
2nd Harmonic Suppression
(dBc)
+25C
+85C
-40C
