Dimensions: Inches(Millimeters)
Tolerance: 0.010 (0.25)
Weight: 6.8 grams
0.709
(18.00)
0.051
(1.30)
0.100
(2.54)
0.394
(10.0)
0.675
(17.15) max.
0.394
(10.00)
0.547
(13.90)
0.098
(2.50)
0.024
(0.60)
Package "S"
Package "T"
TALEMA IN
AEP510-T
Date Code
0.524
(13.30)
max.
0.173
(4.40)
0.535
(13.60)
0.394
(10.00)
ADSL Transformers for Globespan Chipsets
Features
complies with ANSI and ETSI requirements
matched to Globespan's DMT G7000, EL-1501, G7266
and G7266RT chipsets
very low THD
1500V minimum isolation
all materials approved to UL94V-0
excellent quality at competitive price due to high
volume production
manufactured in ISO-9001 approved Talema facility
0.028
(0.71)
0.516
(13.11) max
0.531
(13.50)
max.
TALEMA IN
AEP500-S
Date Code
0.394
(10.0)
0.098(2.50)
Schematic
