TLC274, TLC274A, TLC274B, TLC274Y, TLC279
LinCMOS
TM
PRECISION QUAD OPERATIONAL AMPLIFIERS
SLOS092C SEPTEMBER 1987 REVISED MARCH 1998
1
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
D
Trimmed Offset Voltage:
TLC279 . . . 900
V Max at 25
C,
V
DD
= 5 V
D
Input Offset Voltage Drift . . . Typically
0.1
V/Month, Including the First 30 Days
D
Wide Range of Supply Voltages Over
Specified Temperature Range:
0
C to 70
C . . . 3 V to 16 V
40
C to 85
C . . . 4 V to 16 V
55
C to 125
C . . . 4 V to 16 V
D
Single-Supply Operation
D
Common-Mode Input Voltage Range
Extends Below the Negative Rail (C-Suffix
and I-Suffix Versions)
D
Low Noise . . . Typically 25 nV/
Hz
at f = 1 kHz
D
Output Voltage Range Includes Negative
Rail
D
High Input Impedance . . . 10
12
Typ
D
ESD-Protection Circuitry
D
Small-Outline Package Option Also
Available in Tape and Reel
D
Designed-In Latch-Up Immunity
description
The TLC274 and TLC279 quad operational
amplifiers combine a wide range of input offset
voltage grades with low offset voltage drift, high
input impedance, low noise, and speeds
approaching that of general-purpose BiFET
devices.
These devices use Texas Instruments
silicon-gate LinCMOS
TM
technology, which
provides offset voltage stability far exceeding the
stability available with conventional metal-gate
processes.
The extremely high input impedance, low bias
currents, and high slew rates make these
cost-effective devices ideal for applications which
have previously been reserved for BiFET and
NFET products. Four offset voltage grades are
available (C-suffix and I-suffix types), ranging
from the low-cost TLC274 (10 mV) to the high-
precision TLC279 (900
V). These advantages, in
combination with good common-mode rejection
and supply voltage rejection, make these devices
a good choice for new state-of-the-art designs as
well as for upgrading existing designs.
Copyright
1998, Texas Instruments Incorporated
PRODUCTION DATA information is current as of publication date.
Products conform to specifications per the terms of Texas Instruments
standard warranty. Production processing does not necessarily include
testing of all parameters.
1200
Percentage of Units %
VIO Input Offset Voltage
V
30
1200
0
600
0
600
5
10
15
20
25
VDD = 5 V
TA = 25
C
N Package
DISTRIBUTION OF TLC279
INPUT OFFSET VOLTAGE
1
2
3
4
5
6
7
14
13
12
11
10
9
8
1OUT
1IN
1IN +
V
DD
2IN +
2IN
2OUT
4OUT
4IN
4IN +
GND
3IN +
3IN
3OUT
D, J, N, OR PW PACKAGE
(TOP VIEW)
3
2
1 20 19
9 10 11 12 13
4
5
6
7
8
18
17
16
15
14
4IN +
NC
GND
NC
3IN +
1IN +
NC
V
DD
NC
2IN +
FK PACKAGE
(TOP VIEW)
1IN
1OUT
NC
3OUT
3IN
4OUT
4IN
2IN
2OUT
NC
NC No internal connection
290 Units Tested From 2 Wafer Lots
LinCMOS is a trademark of Texas Instruments Incorporated.
TLC274, TLC274A, TLC274B, TLC274Y, TLC279
LinCMOS
TM
PRECISION QUAD OPERATIONAL AMPLIFIERS
SLOS092C SEPTEMBER 1987 REVISED MARCH 1998
2
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
description (continued)
In general, many features associated with bipolar technology are available on LinCMOS
TM
operational
amplifiers, without the power penalties of bipolar technology. General applications such as transducer
interfacing, analog calculations, amplifier blocks, active filters, and signal buffering are easily designed with the
TLC274 and TLC279. The devices also exhibit low voltage single-supply operation, making them ideally suited
for remote and inaccessible battery-powered applications. The common-mode input voltage range includes the
negative rail.
A wide range of packaging options is available, including small-outline and chip-carrier versions for high-density
system applications.
The device inputs and outputs are designed to withstand 100-mA surge currents without sustaining latch-up.
The TLC274 and TLC279 incorporate internal ESD-protection circuits that prevent functional failures at voltages
up to 2000 V as tested under MIL-STD-883C, Method 3015.2; however, care should be exercised in handling
these devices as exposure to ESD may result in the degradation of the device parametric performance.
The C-suffix devices are characterized for operation from 0
C to 70
C. The I-suffix devices are characterized
for operation from 40
C to 85
C. The M-suffix devices are characterized for operation over the full military
temperature range of 55
C to 125
C.
AVAILABLE OPTIONS
PACKAGED DEVICES
CHIP
TA
VIOmax
AT 25
C
SMALL
OUTLINE
(D)
CHIP
CARRIER
(FK)
CERAMIC
DIP
(J)
PLASTIC
DIP
(N)
TSSOP
(PW)
CHIP
FORM
(Y)
0
C to 70
C
900
V
2 mV
5 mV
10 mV
TLC279CD
TLC274BCD
TLC274ACD
TLC274CD
--
--
--
--
--
--
--
--
TLC279CN
TLC274BCN
TLC274ACN
TLC274CN
--
--
--
TLC274CPW
--
--
--
TLC274Y
900
V
TLC279ID
--
--
TLC279IN
--
--
40
C to 85
C
900
V
2 mV
TLC279ID
TLC274BID
--
--
TLC279IN
TLC274BIN
--
--
40
C to 85
C
5 mV
TLC274AID
--
--
TLC274AIN
--
--
10 mV
TLC274ID
--
--
TLC274IN
--
--
55
C to 125
C
900
V
10 mV
TLC279MD
TLC274MD
TLC279MFK
TLC274MFK
TLC279MJ
TLC274MJ
TLC279MN
TLC274MN
--
--
--
--
The D package is available taped and reeled. Add R suffix to the device type (e.g., TLC279CDR).
TLC274, TLC274A, TLC274B, TLC274Y, TLC279
LinCMOS
TM
PRECISION QUAD OPERATIONAL AMPLIFIERS
SLOS092C SEPTEMBER 1987 REVISED MARCH 1998
3
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
equivalent schematic (each amplifier)
VDD
P4
P3
R6
N5
R2
P2
R1
P1
IN
IN +
N1
R3
D1
R4
D2
N2
GND
N3
R5
C1
N4
R7
N6
N7
OUT
P6
P5
TLC274, TLC274A, TLC274B, TLC274Y, TLC279
LinCMOS
TM
PRECISION QUAD OPERATIONAL AMPLIFIERS
SLOS092C SEPTEMBER 1987 REVISED MARCH 1998
4
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
TLC274Y chip information
These chips, when properly assembled, display characteristics similar to the TLC274C. Thermal compression
or ultrasonic bonding may be used on the doped-aluminum bonding pads. Chips may be mounted with
conductive epoxy or a gold-silicon preform.
BONDING PAD ASSIGNMENTS
CHIP THICKNESS: 15 TYPICAL
BONDING PADS: 4
4 MINIMUM
TJmax = 150
C
TOLERANCES ARE
10%.
ALL DIMENSIONS ARE IN MILS.
PIN (11) IS INTERNALLY CONNECTED
TO BACKSIDE OF CHIP.
+
1OUT
1IN +
1IN
VDD
(4)
(6)
(3)
(2)
(5)
(1)
+
(7)
2IN +
2IN
2OUT
11
GND
+
3OUT
3IN +
3IN
(13)
(10)
(9)
(12)
(8)
+
(14)
4OUT
4IN +
4IN
68
108
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
TLC274, TLC274A, TLC274B, TLC274Y, TLC279
LinCMOS
TM
PRECISION QUAD OPERATIONAL AMPLIFIERS
SLOS092C SEPTEMBER 1987 REVISED MARCH 1998
5
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
absolute maximum ratings over operating free-air temperature range (unless otherwise noted)
Supply voltage, V
DD
(see Note 1)
18 V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Differential input voltage, V
ID
(see Note 2)
V
DD
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input voltage range, V
I
(any input)
0.3 V to V
DD
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Input current, I
I
5 mA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Output current, l
O
(each output)
30 mA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Total current into V
DD
45 mA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Total current out of GND
45 mA
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Duration of short-circuit current at (or below) 25
C (see Note 3)
unlimited
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Continuous total dissipation
See Dissipation Rating Table
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Operating free-air temperature, T
A
: C suffix
0
C to 70
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I suffix
40
C to 85
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
M suffix
55
C to 125
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Storage temperature range
65
C to 150
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Case temperature for 60 seconds: FK package
260
C
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds: D, N, or PW package
260
C
. . . . . . . . . . . .
Lead temperature 1,6 mm (1/16 inch) from case for 60 seconds: J package
300
C
. . . . . . . . . . . . . . . . . . . . .
Stresses beyond those listed under "absolute maximum ratings" may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under "recommended operating conditions" is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
NOTES:
1. All voltage values, except differential voltages, are with respect to network ground.
2. Differential voltages are at the noninverting input with respect to the inverting input.
3. The output may be shorted to either supply. Temperature and/or supply voltages must be limited to ensure that the maximum
dissipation rating is not exceeded (see application section).
DISSIPATION RATING TABLE
PACKAGE
TA
25
C
POWER RATING
DERATING FACTOR
ABOVE TA = 25
C
TA = 70
C
POWER RATING
TA = 85
C
POWER RATING
TA = 125
C
POWER RATING
D
950 mW
7.6 mW/
C
608 mW
494 mW
--
FK
1375 mW
11.0 mW/
C
880 mW
715 mW
275 mW
J
1375 mW
11.0 mW/
C
880 mW
715 mW
275 mW
N
1575 mW
12.6 mW/
C
1008 mW
819 mW
--
PW
700 mW
5.6 mW/
C
448 mW
--
--
recommended operating conditions
C SUFFIX
I SUFFIX
M SUFFIX
UNIT
MIN
MAX
MIN
MAX
MIN
MAX
UNIT
Supply voltage, VDD
3
16
4
16
4
16
V
Common mode input voltage VIC
VDD = 5 V
0.2
3.5
0.2
3.5
0
3.5
V
Common-mode input voltage, VIC
VDD = 10 V
0.2
8.5
0.2
8.5
0
8.5
V
Operating free-air temperature, TA
0
70
40
85
55
125
C
