Positive Voltage Regulators
Series
285
3
The XC62FP series is a group of positive voltage output, three-pin
regulators, that provide a high current even when the input/output
voltage differential is small. Low power consumption and high accuracy
is achieved through CMOS and laser trimming technologies.
The XC62FP consists of a high-precision voltage reference, an error
amplification circuit, and a current limited output driver. Transient
response to load variations have improved in comparison to the existing
series.
SOT-23 (150mW), SOT-89 (500mW) and TO-92 (300mW) packages are
available.
Maximum Output Current
: 250mA
(within max. power dissipation, V
OUT
= 5.0V)
Output Voltage Range
: 2.0V ~ 6.0V in 0.1V increments
(1.5V ~ 1.9V for custom products)
Highly Accurate: Output voltage 2%
(1% for semi-custom products)
Low Power Consumption
: Typ. 2.0
A @ V
OUT
=5.0V
Output Voltage Temperature Characteristics
: Typ. 100ppm/C
Input Stability
: Typ. 0.2%/V
Small Input-Output Differential
: I
OUT
= 100mA @ V
OUT
= 5.0V with a
0.12V differential.
Ultra Small Packages
: SOT-23 (150mW) mini-mold,
SOT-89 (500mW) mini-power mold
TO-92 (300mW)
GBattery Powered Equipment
GPalmtops
GPortable Cameras and Video Recorders
GReference Voltage Sources
NCMOS Low Power Consumption
NSmall Input-Output Voltage Differential
: 0.12V @ 100mA,
0.38V @ 200mA
NMaximum Output Current : 250mA (V
OUT
=5.0V)
NOutput Voltage Range
: 2.0V~6.0V
NHighly Accurate
: 2% (1%)
V
IN
V
IN
V
OUT
V
ss
R
L
C
IN
1
F
Tantalum
C
L
1
F
Tantalum
0
1
2
3
0
2
4
6
8
10
Topr=25
85
-40
XC62FP3002 (3V)
Supply Current:Iss (
A)
Input Voltage:V
IN
(V)
General Description
Features
Applications
Typical Application Circuit
Typical Performance
Characteristic
03S_05XC62FP 02.10.7 5:18 PM 285
XC62FP
Series
286
3
SOT-23
TOP VIEW
SOT-89
TOP VIEW
3
1
2
V
OUT
V
SS
SS
V
OUT
V
IN
V
IN
1
2
3
PIN NUMBER
SOT-23
SOT-89
FUNCTION
1
1
Supply voltage input
Ground
Regulated voltage output
3
2
2
3
TO-92 (L)
PIN NAME
2
1
3
TO-92 (T)
1
2
3
V
IN
V
SS
V
OUT
Product Classification
GOrdering Information
DESIGNATOR
a
e
f
b
c
d
DESCRIPTION
DESIGNATOR
DESCRIPTION
Polarity of Output Voltage:
P: + (Positive)
Temperature Coefficients:
0=
100ppm (typical)
Output Voltage
30=3.0V
50=5.0V
Output Voltage Accuracy:
1=
1.0% (Semi-custom)
2=
2.0%
Package Type
M=SOT-23
P=SOT-89
T=TO-92 (Standard)
L=TO-92 (Custom pin configuration)
Device Orientation
R=Embossed Tape
(Standard Feed)
L=Embossed Tape
(Reverse Feed)
H=Paper Tape (TO-92)
B=Bag (TO-92)
X C 6 2 F X X X X X X X
a
b
c
d
e
f
1
2
3
TO-92T Type
TOP VIEW
V
IN
V
OUT
V
SS
1
2
3
TO-92 (L Type)
TOP VIEW
V
IN
V
SS
V
OUT
Pin Configuration
Pin Assignment
03S_05XC62FP 02.9.12 3:01 PM 286
XC62FP
Series
288
3
Marking
GSOT-23, SOT-89
q Represents the integer of the Output Voltage
SYMBOL
VOLTAGE(V)
2
2.w
1
1.w
4
4.w
3
3.w
SYMBOL
VOLTAGE(V)
6
6.w
5
5.w
w Represents the decimal number of the Output Voltage
SYMBOL
VOLTAGE(V)
SYMBOL
VOLTAGE(V)
B
q.1
H
A
q.0
F
D
q.3
L
q.8
C
q.2
q.6
q.5
q.7
K
E
q.4
M
q.9
r Represents the assembly lot no.
Based on internal standards
SYMBOL
0
e Based on internal standards
SOT-23
TOP VIEW
SOT-89
TOP VIEW
1 2 3 4
1
2
3
4
GTO-92
3.70.3
10.0min
1.60.1
0.40.05
4.65
0.450.1
2.5
+0.4
-0.1
2.5
+0.4
-0.1
+0.35
-0.45
4.8
+0.4
-0.5
03S_05XC62FP 02.9.12 3:01 PM 288
Absolute Maximum Ratings
Block Diagram
V
OUT
V
IN
V
SS
+
-
Current
Limit
Voltage
Reference
PARAMETER
Input Voltage
Output Voltage
Output Current
SOT-23
Continuous
Total Power
Dissipation
SOT-89
Operating Ambient
Temperature
Storage Temperature
RATINGS
12
500
150
500
TO-92
300
40 ~ +85
40 ~ +125
UNITS
V
V
mA
mW
C
C
SYMBOL
V
IN
V
OUT
I
OUT
P
d
T
opr
T
stg
Ta=25
C
V
SS
-0.3 ~ V
IN
+0.3
GTO-92
2 3 4 5
6 7
1
TO-92L Type
(TOP VIEW)
62F
L
2 3 4 5
6 7
1
TO-92T Type
(TOP VIEW)
62F
q Represents the polarity of
Output Voltage
DESIGNATOR
CONFIGURATION
P
CMOS
we Represents the Detect Voltage
w
3
3.3
5
5.0
e
DESIGNATOR
VOLTAGEV
3
0
r Represents the temperature
characteristics
DESIGNATOR TEMPERATURE CHARACTERISTICS
0
TPY100ppm
DESIGNATOR DETECT VOLTAGE ACCURACY
1
within 1semi-custom
2
within 2
t Represents the Detect
Voltage Accuracy
y Represents a least significant
digit of the produced year
DESIGNATOR
PRODUCED YEAR
0
2000
1
2001
u Denotes the production lot number
0 to 9, A to Z repeated (G.I.J.O.Q.W excepted)
XC62FP
Series
289
3
03S_05XC62FP 02.9.12 3:01 PM 289
