RN1401,RN1402,RN1403,RN1404,RN1405,RN1406
2001-06-07
1
TOSHIBA Transistor Silicon NPN Epitaxial Type (PCT Process)
RN1401,RN1402,RN1403
RN1404,RN1405,RN1406
Switching, Inverter Circuit, Interface Circuit
And Driver Circuit Applications
l With built-in bias resistors
l Simplify circuit design
l Reduce a quantity of parts and manufacturing process
l Complementary to RN2401~RN2406
Equivalent Circuit and Bias Resister Values
Maximum Ratings
(Ta = 25C)
Characteristic Symbol
Rating
Unit
Collector-base voltage
V
CBO
50 V
Collector-emitter voltage
RN1401~1406
V
CEO
50 V
RN1401~1404 10
Emitter-base voltage
RN1405, 1406
V
EBO
5
V
Collector current
I
C
100
mA
Collector power dissipation
P
C
200
mW
Junction temperature
T
j
150
C
Storage temperature range
RN1401~1406
T
stg
-55~150
C
JEDEC TO-236MOD
EIAJ SC-59
TOSHIBA 2-3F1A
Weight: 0.012g
Unit: mm
Type No.
R1 (k R2
(k
RN1401 4.7
4.7
RN1402 10 10
RN1403 22 22
RN1404 47 47
RN1405 2.2 47
RN1406 4.7 47
RN1401,RN1402,RN1403,RN1404,RN1405,RN1406
2001-06-07
2
Electrical Characteristics
(Ta = 25C)
Characteristic Symbol
Test
Circuit
Test Condition
Min
Typ.
Max
Unit
I
CBO
V
CB
= 50V, I
E
= 0
100
Collector cut-off
current
RN1401~1406
I
CEO
V
CE
= 50V, I
B
= 0
500
nA
RN1401 0.82
1.52
RN1402 0.38
0.71
RN1403 0.17
0.33
RN1404
V
EB
= 10V, I
C
= 0
0.082
0.15
RN1405 0.078
0.145
Emitter cut-off current
RN1406
I
EBO
V
EB
= 5V, I
C
= 0
0.074
0.138
mA
RN1401 30
RN1402 50
RN1403 70
RN1404 80
RN1405 80
DC current gain
RN1406
h
FE
V
CE
= 5V, I
C
= 10mA
80
Collector-emitter
saturation voltage
RN1401~1406
V
CE (sat)
I
C
= 5mA, I
B
= 0.25mA
0.1 0.3 V
RN1401
1.1
2.0
RN1402
1.2
2.4
RN1403
1.3
3.0
RN1404
1.5
5.0
RN1405
0.6
1.1
Input voltage (ON)
RN1406
V
I (ON)
V
CE
= 0.2V, I
C
= 5mA
0.7
1.3
V
RN1401~1404
1.0
1.5
Input voltage (OFF)
RN1405, 1406
V
I (OFF)
V
CE
= 5V, I
C
= 0.1mA
0.5
0.8
V
Transition frequency RN1401~1406
f
T
V
CE
= 10V, I
C
= 5mA
250
MHz
Collector Output
capacitance
RN1401~1406
C
ob
V
CB
= 10V, I
E
= 0,
f = 1MHz
3 6 pF
RN1401
3.29 4.7 6.11
RN1402
7 10 13
RN1403
15.4 22 28.6
RN1404
32.9 47 61.1
RN1405
1.54 2.2 2.86
Input resistor
RN1406
R1
3.29 4.7 6.11
k
RN1401~1404
0.9 1.0 1.1
RN1405
0.0421 0.0468 0.0515
Resistor ratio
RN1406
R1/R2
0.09 0.1 0.11
RN1401,RN1402,RN1403,RN1404,RN1405,RN1406
2001-06-07
3
RN1401,RN1402,RN1403,RN1404,RN1405,RN1406
2001-06-07
4
RN1401,RN1402,RN1403,RN1404,RN1405,RN1406
2001-06-07
5
