U20JL2C48A
2004-07-07
1
TOSHIBA HIGH EFFICIENCY DIODE STACK (HED) SILICON EPITAXIAL TYPE
U20JL2C48A
SWITCHING MODE POWER SUPPLY APPLICATION
CONVERTER & CHOPPER APPLICATION

Repetitive Peak Reverse Voltage
: V
RRM
= 600V
Average Output Rectified Current
: I
O
= 20A
Ultra Fast Reverse-Recovery Time : t
rr
= 35ns (Max)
Low Switching Losses and Output Noise.
MAXIMUM RATINGS
(Ta = 25C)
CHARACTERISTIC SYMBOL
RATING
UNIT
Repetitive Peak Reverse Voltage
V
RRM
600 V
Average Output Rectified Current
I
O
20 A
80 (50Hz)
Peak One Cycle Surge Forward
Current (Sin Wave)
I
FSM
88 (60Hz)
A
Junction Temperature
T
j
-40~150 C
Storage Temperature Range
T
stg
-40~150 C
ELECTRICAL CHARACTERISTICS
(Ta = 25C)
CHARACTERISTIC SYMBOL TEST
CONDITION MIN
MAX
UNIT
Peak Forward Voltage
V
FM
I
FM
= 10A
3.2 V
Repetitive Peak Reverse Current
I
RRM
V
RRM
= 600V
50 A
Reverse Recovery Time
t
rr
I
F
= 2A, di / dt = -50A / s
35 ns
Forward Recovery Time
t
fr
I
F
= 1A
100 ns
Thermal Resistance
R
th
(j-c)
Total DC, Junction to Case
1.6
C
/
W
Note 1: V
FM
, I
RRM
, t
rr
, t
fr
A value applied to one cell.
POLARITY MARKING


Unit: mm
3
0.
2
JEDEC
JEITA
TOSHIBA 12-10D2A
Abbreviation Code
Part No.
20JL2C U20JL2C48A
Lot No.
With underline:
Lead (Pb)-Free or
Lead (Pb)-Free Finish
20JL2C
Characteristic
distinguishing mark
Part No. (or brevity code)
U20JL2C48A
2004-07-07
2
Handling Precaution
The maximum ratings denote the absolute maximum ratings, which are rated values and must not be exceeded
during operation, even for an instant. The following are the general derating methods that we recommend when
you design a circuit with a device.
V
RRM
: We recommend that the worst case voltage, including surge voltage, be no greater than 80% of the
maximum rating of V
RRM
for a DC circuit and be no greater than 50% of that of V
RRM
for an AC
circuit. V
RRM
has a temperature coefficient of 0.1%/C. Take this temperature coefficient into
account designing a device at low temperature.
I
O
:
We recommend that the worst case current be no greater than 80% of the maximum rating of I
O
.
Carry out adequate heat design. If you can't design a circuit with excellent heat radiation, set the
margin by using an allowable Tamax-I
O
curve.
This rating specifies the non-repetitive peak current in one cycle of a 50-Hz sine wave, condition angle 180.
Therefore, this is only applied for an abnormal operation, which seldom occurs during the lifespan of the device.
We recommend that a device be used at a Tj of below 120C under the worst load and heat radiation conditions.
Please refer to the Rectifiers databook for further information.
U20JL2C48A
2004-07-07
3
U20JL2C48A
2004-07-07
4
