TOSHIBA Schottky Barrier Rectifier Stack Schottky Barrier Type
U5GWJ2C42C
Switching Mode Power Supply Application
Peak forward voltage: V
FM
= 0.55 V (max)
Repetitive peak reverse voltage: V
RRM
= 40 V
Average output rectified current: I
O
= 5 A
Maximum Ratings
(Ta
=
25C)
Characteristics Symbol
Rating
Unit
Repetitive peak reverse voltage
V
RRM
40 V
Average output rectified current
I
O
5.0
A
Peak one cycle surge forward current
I
FSM
50 (50 Hz)
A
Junction temperature
T
j
-40~150 C
Storage temperature range
T
stg
-40~150 C
Polarity
Electrical Characteristics
(Ta
=
25C)
Characteristics Symbol
Test
Condition
Min
Typ.
Max
Unit
Peak forward voltage
V
FM
I
FM
= 2.5 A
0.55 V
Repetitive peak reverse current
I
RRM
V
RRM
= Rated (40 V)
3.5 mA
Junction capacitance
C
j
V
R
= 10 V, f = 1.0 MHz
100
pF
Thermal resistance
R
th (j-c)
Total
DC
3.5
C/W
Note: V
FM
, I
RRM
, Cj: A value applied to one cell.
Marking
Abbreviation Code
Part No.
5GWJ2 U5GWJ2C42C
Unit: mm
JEDEC
JEITA SC-64
TOSHIBA 12-7B2A
Weight: 0.3 g (typ.)
1
3
2
5GWJ2
Lot No.
A line indicates
lead (Pb)-free package or
lead (Pb)-free finish.
Part No. (or abbreviation code)
U5GWJ2C42C
2004-07-07
2
Handling Precaution
Schottky barrier diodes have reverse current characteristics compared to other diodes.
There is a possibility SBD may cause thermal runaway when it is used under high temperature or high voltage.
Please take forward and reverse loss into consideration during design.
The maximum ratings denote the absolute maximum ratings, which are rated values and must not be exceeded
during operation, even for an instant. The following are the general derating methods that we recommend when
you design a circuit with a device.
V
RRM
: Use this rating with reference to the above. V
RRM
has a temperature coefficient of 0.1%/C. Take
this temperature coefficient into account designing a device at low temperature.
I
O
:
We recommend that the worst case current be no greater than 80% of the maximum rating of I
O
and
T
j
be below 100C. When using this device, take the margin into consideration by using an
allowable Tamax-I
O
curve.
I
FSM
:
This rating specifies the non-repetitive peak current. This is only applied for an abnormal operation,
which seldom occurs during the lifespan of the device.
T
j
:
Derate this rating when using a device in order to ensure high reliability. We recommend that the
device be used at a T
j
of below 100C.
Please refer to the Rectifiers databook for further information.
