NPN TRIPLE DIFFUSED
2SD1876
PLANAR SILICON TRANSISTOR
COLOR TV HORIZONTAL OUTPUT
APPLICATIONS(Damper Diode BUILT IN)
!
High Collector-Base Voltage(V
CBO
=1500V)
TO-3PML
!
High Speed Switching
ABSOLUTE MAXIMUM RATINGS (T
a
=2
5
o
C)
Characteristic
Symbol
Rating
Unit
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base voltage
Collector Current (DC)
Collector Dissipation (Tc=25
o
C
)
Junction Temperature
Storage Temperature
V
CBO
V
CEO
V
EBO
I
C
P
C
T
j
Tstg
1500
1500
6
3
50
150
-50~150
V
V
V
A
W
o
C
o
C
ELECTRICAL CHARACTERISTICS (T
a
=25
o
C)
Characterristic
Symbol
Test Condition
Min
Typ
Max
Unit
Collector- Emitter Cutoff Current(V
BE
=0)
Collector Cutoff Current
Emitter Cutoff Current
DC Current Gain
Collector- Emitter Saturation Voltage
I
CES
I
CBO
I
EBO
h
FE
V
CE(sat)
V
CE
= 1400 V ,
R
BE
=0
V
CB
= 800 V , I
E
=0
V
EB
= 4V , I
C
=
0
V
CE
= 5V ,
I
C
=1A
I
C
= 2A , I
B
=
0.6A
8
1.0
10
1.0
5.0
mA
A
mA
V
Wing Shing Computer Components Co., (H.
K
)L td . TeL :(852)234 1 92 76
Fax : (852)27 97
8153 .
