Features
Programmable data word length, parity and stop bits
Parity, overrun and framing error checking instructions
and counting loop interactions
Supports transmission rates over the 1.0 Mbps spec
False start bit deletion
Peripheral modem control functions
Functionality based on the Motorola MC6850
Applications
The C6850 core is used in serial data communications and
modem applications.
AllianceCORETM Facts
Core Specifics
See Table 1
Provided with Core
Documentation
Core design document
Design File Formats
EDIF, .ngo, .XNF Netlist;
VHDL Source RTL
available extra
Constraints File
C6850.ucf
Verification
VHDL testbench, test vectors
Instantiantion Templates
Viewlogic
Reference designs & ap-
plication notes
None
Additional Items
None
Simulation Tool Used
1076-compliant VHDL Verilog simulator
Support
Support provided by CAST, Inc.
Table 1: Core Implementation Data
Supported
Family
Device
Tested
CLB
Slices
2
Clock
IOBs
IOBs
1
Performance
(MHz)
Xilinx
Tools
Special
Features
Virtex
V50-6
97
2
27
92
M2.1i
None
Virtex-E
V50E-8
97
2
27
129
M2.1i
None
Spartan-II
2S50-6
97
2
27
96
M2.1i
None
Notes:
1. Assuming all core I/Os are routed off-chip.
2. Optimized for speed.
C6850 Asynchronous
Communication Interface
Adapter
June 26, 2000
Product Specification
C6850 Asynchronous Communication Interface Adapter
3-2
June 26, 2000
General Description
The C6850 asynchronous communications interface
(ACIA) core provides data formatting and control to the
asynchronous data communications of data bus systems.
The core has select, enable, read/write, interrupt and bus
interface logic features that allow data transfers over an 8-
bit bi-directional parallel data bus system. With proper for-
matting and error checking, the core can transmit and
receive serial data.
In addition, a programmable control register provides the
core with a transmit control, a receive control, an interrupt
control, variable word lengths and clock division ratios.
Three control lines are provided for peripheral or modem
operation
Functional Description
The C6850 core is partitioned into modules as shown in
Figure 1 and described below.
Modem Control
The Modem Control Logic consists of a set of signals that
can be used to interface with almost any modem. These
standard signals consist of CTSn, RTSn and DCDn. The
Transmit and Receive Control Blocks and Control Register
Block monitor and control these signals.
Receiver
The Receiver section accepts serial data and converts to
parallel format. It also checks for parity, framing, overrun,
and break and then sends the formatted data to the CPU.
The Receiver section is made up of the Parity Checker,
Clock Generator, Serial to Parallel and the Receive Data
Register.
Transmitter
The Transmitter section accepts parallel data from the Data
Bus Buffer, converts it to serial inserting all required bits
depending on the communication protocol and outputs the
formatted serial stream to the TxData output pin. The
Transmitter section is made up of the Transmit Data Regis-
ter, Transmit Control, Clock Generator, Parity Generator,
Parallel to Serial and Interrupt Logic Blocks.
Status Register
Information on status of C6850 is available to CPU by read-
ing the status register (read only register).
Output MUX
The Output MUX selects between the Status register and
the data register.
Figure 1: C6850 Block Diagram
DO[7:0]
TXDATA
IRQn
RS
TX_CLK
CSn
RXW
RX_CLK
RXDATA
E
EXT_RST
CTSn
RTSn
DCDn
DIN[7:0]
Data
Bus
Buffers
Chip
Select &
R/W
Control
CPU
INTERFACE
TRANSMITTER
RECEIVER
Transmit
Control
Interupt
Logic
Parity
Checker
Receive
Control
Parallel
to
Serial
Serial
to
Parallel
Clock
Gen
Clock
Gen
Out
Mux
Parity
Gen
Transmit
Data
Register
Recieve
Data
Register
Status
Register
Control
Register
MODEM CONTROL
x8806
June 26, 2000
3-3
CAST, Inc.
CPU Interface
The CPU Interface receives control signals from the CPU.
These signals consist of the data bus read and write sig-
nals, chip selects, reset and master clock signals. The Data
Bus Buffer Block is used by the CPU to write data to the
device using the above signals.
Core Modifications
The C6850 core can be customized to include a 16 bit
Internal Baud Rate Generator. Features which are not
required can be removed to improve the efficiency of the
layout.
Please contact CAST directly for any required modifica-
tions.
Pinout
The pinout of the C6850 core has not been fixed to specific
FPGA I/O, allowing flexibility with a user's application. Sig-
nal names are shown in the block diagram in Figure 1 and
described in Table 2.
Verification Methods
The C6850 core's functionality was verified by means of a
proprietary hardware modeler. The same stimulus was
applied to a hardware model which contained the original
Motorola chip, and the results compared with the core's
simulation outputs.
Recommended Design
Experience
The user must be familiar with HDL design methodology as
well as instantiation of Xilinx netlists in a hierarchical design
environment.
Ordering Information
The C6850 core is available from CAST, Inc. The C6850
core is licensed from Moxsyn S.r.l. Please contact CAST,
Inc. directly for pricing and information.
Related Information
Microprocessor, Microcontroller and
Peripheral Data Book (Vol. II),1988
Contact:
Motorola Inc.
Literature Distribution Center
6501 William Cannon Drive West
Austin, Texas 78735-8598
URL: http://motorola.com
Xilinx Programmable Logic
For information on Xilinx programmable logic or develop-
ment system software, contact your local Xilinx sales office,
or:
Xilinx, Inc.
2100 Logic Drive
San Jose, CA 95124
Phone:
+1 408-559-7778
Fax:
+1 408-559-7114
URL:
www.xilinx.com
Table 2: Core Signal Pinout
Signal
Signal
Direction
Description
TX_CLK
Input
Transmit clock; uses 1 glo-
bal IOB pin
RS
Input
Register Select
CSn
Input
Chip Select
RXW
Input
Read /Write
E
Input
Enable (clock); uses 1 glo-
bal IOB pin
EXT_RST
Input
External reset
DIN[7:0]
Input
Data Input Bus
RX_CLK
Input
Receive clock; uses 1 global
IOB pin
RXDATA
Input
Receive Data
TXDATA
Output
Transmit Data
IRQn
Output
Interrupt Request
CTSn
Input
Clear-to-Send
RTSn
Output
Request-to-Send
DCDn
Input
Data Carrier Detect; uses 1
global IOB pin
D0[7:0]
Output
Data Output Bus
