6.00mm
(0.236") PITCH CONNECTOR
I/NO
TITLE
DESCRIPTION
MATERIAL
1
SMH600-04B
HOUSING
PA66, PP UL 94V2 Grade
Material
SMH600-NNB Series
Wire-to-Board
Housing
ITEM
SPEC
Contact Resistance
Current Rating
Operating Temperature
Voltage Rating
AC/DC 250V
30m MAX
Withstanding Voltage
AC1500V/1min
Insulation Resistance
1000M MIN
Applicable P.C.B
-
Applicable Wire
AWG #14~#22
Applicable FPC/FFC
-
-
Solder Height
Crimp Tensile Strength
-
UL FILE NO
-
AC/DC 15A
-25~+85
Specification
Application Terminal : SMT603B-L (221 page)
TERMINAL ASSEMBLY DRAWING
AWG #14 ~ #22
1
5
.
3
3
.
7
6.0
22.0
1
.
0
6.60
14.0
11.6
