05D
4 to 6 VDC
Voltage
12D
9.6 to 14.4 VDC
24D
19.2 to 28.8 VDC
Input
Turn-on
05D
4 VDC
Voltage
12D
9.6 VDC
24D
19.2 VDC
Current
15 mA
Turn-off voltage
1 VDC
Voltage Range
50 to 250 VAC
Current Rating (max.)
2 A
Inrush Current (non repetitive)
30 A
Voltage Drop (max.)
1.5 VAC
Minimum Load Current
15 mA
Leakage Current (max.)
1.5 mA
Zero Voltage Switching
Yes
Output
Min. Off-state Dv/Dt at Maximum Rated Voltage
15 V/us
Frequency Range
47 to 70 Hz
Time Turn-on
1/2 of cycle +1 ms
Time Turn-off
1/2 of cycle +1 ms
Dielectric Strength
2000 VAC, 1 min.
General
Insulation Resistance
1000M
min. at 500 VDC
Characteristics
Ambient Temp. Range (operating)
-30C (-22F) to 80C (176F)
Termination
PCB terminal
Weight
Approximately 5 grams
Construction
Fully sealed
SGC-4F
6/3/03W
SOLID STATE RELAY
2 AMP 250 VAC
FEATURES
Photo isolation
600V blocking voltage
Both "Zero Voltage" and phase controllable
"Random" Switching versions
High surge capability
PCB mount
UL, CUR file E43203
MECHANICAL DATA
Load current vs. ambient temperature characteristics
3
-
4
1
2
LOAD
+
LOAD
+
-
1
2
3
4
.171
[4.35]
.056
[1.42]
.100/[2.54] GRID
[1.0]
4 x .039
4 x .039
[1.0]
TERMINAL STYLE "M"
TERMINAL STYLE "T"
PC BOARD LAYOUT
WIRING DIAGRAM
PC BOARD LAYOUT
WIRING DIAGRAM
Viewed toward terminals
Viewed toward terminals
Viewed toward terminals
Viewed toward terminals
[0.7]
4 x .028
[0.7]
4 x .028
[0.4]
4 x .016
[6.5]
.256
[4.0]
4 x .157
[20.0]
.787
[24.0]
.945
.100/[2.54] GRID
.171
[4.35]
[1.42]
.056
.787
.256
[6.5]
[4.0]
4 x .157
[0.4]
4 x .016
[20.0]
.945
[24.0]
SGC-4F
6/3/03W
RELAY ORDERING DATA
SGC-4F
05
D
0
T
MODEL
INPUT
INPUT
OUTPUT
TERMINAL ARRANGEMENT/
VOLTAGE
FORM
FORM
MOUNT FORM
05: 4 to 6V
D: DC
0: Zero-cross
T: Pin T
12: 9.6 to 14.4V
1: Random Phase
M: Pin M
24: 19.2 to 28.8V
Dimensions in inches with metric equivalents in parentheses. Tolerance: .010"
2.5
2.0
1.5
1.0
0.5
0
Ambient temperature C
Load current (A)
-40 -20
0
20 40
60 80 100
Inrush current resistivity Non-repetitive
300
1000
3000
5000
0
10
20
30
30
50 100
10
Duration
Inrush current (A) peak
