High Power 5 to 500 MHz
Amplifier
Coaxial
ZHL-5W-1
CASE STYLE: DDD131
Outline Dimensions ( )
inch
mm
Maximum Ratings
Features
Operating Temperature
-20C to 65C
Storage Temperature
-55C to 100C
DC Voltage
+25V Max.
Outline Drawing
Amplifier Electrical Specifications
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
REV. OR
M98142
ZHL-5W-1
051229
Page 1 of 2
wideband, 5 to 500 MHz
high power output, +37 dBm min.
high gain, 40 dB min.
low noise, 4 dB typ.
high IP3, +49 dBm typ.
MODEL
NO.
FREQUENCY
(MHz)
GAIN
(dB)
MAXIMUM
POWER
(dBm)
DYNAMIC
RANGE
VSWR
(:1)
DC
POWER
f
L
f
U
Min.
Flatness
Max.
Output
(1 dB
compr.)
Min.
Input
(no dam-
age)
NF
(dB)
Typ.
IP3
(dBm)
Typ.
In
Out
Volt
(V)
Nom.
Current
(A)
Max.
ZHL-5W-1
5
500
40
1.7
+37
0
4
+49
2.0
2.5
24
3.3
Applications
VHF/UHF
instrumentation
laboratory
Open load is not recommended, potentially can cause damage.
With no load derate max input power by 20 dB
Connectors
Model
Price
Qty.
SMA
ZHL-5W-1
$995.00
(1-9)
A
B
C
D
E
F
G
H
J
K
7.00
3.25
3.13
.25 6.500
.38 2.500
.156
.88
.43
177.80
82.55
79.50
6.35 165.10
9.65
63.50
3.96
22.35
10.92
L
M
N
P
Q
R
S
T
wt
.62
1.00
2.63
.125
.50
6.00
2.23
8.35
grams
15.75
25.40
66.80
3.18
12.70 152.40
56.64 212.09
1884
ZHL-5W-1
Typical Performance Data/Curves
INTERNET
http://www.minicircuits.com
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
Distribution Centers NORTH AMERICA 800-654-7949 417-335-5935 Fax 417-335-5945 EUROPE 44-1252-832600 Fax 44-1252-837010
Mini-Circuits
Mini-Circuits ISO 9001 & ISO 14001 Certified
Page 2 of 2
FREQUENCY
(MHz)
GAIN
(dB)
VSWR
(:1)
POUT at
1 dB
COMPR.
(dBm)
FREQUENCY
(MHz)
NOISE
FIGURE
(dB)
23V
24V
25
IN
OUT
24V
24V
ZHL-5W-1
GAIN
40
42
44
46
48
50
0
100
200
300
400
500
FREQUENCY (MHz)
G
A
I
N
(
d
B
)
23V
24V
25V
ZHL-5W-1
VSWR
1.0
1.5
2.0
2.5
3.0
3.5
0
100
200
300
400
500
FREQUENCY (MHz)
V
S
W
R
IN
OUT
ZHL-5W-1
OUTPUT POWER AT 1-dB COMPRESSION
35
37
39
41
43
45
0
100
200
300
400
500
FREQUENCY (MHz)
O
U
T
P
U
T
P
O
W
E
R
(
d
B
m
)
ZHL-5W-1
NOISE FIGURE
2.0
3.0
4.0
5.0
6.0
7.0
0
100
200
300
400
500
FREQUENCY (MHz)
N
O
I
S
E
F
I
G
U
R
E
(
d
B
)
at 24V
5.00
44.82
44.8
44.79
1.41
2.24
38.75
10.00
4.67
10.00
45.77
45.76
45.71
1.18
2.22
39.69
100.00
3.79
50.00
45.99
45.96
45.93
1.12
2.22
39.68
200.00
3.87
100.00
46.37
46.40
46.40
1.09
2.30
39.68
300.00
3.96
140.00
46.26
46.32
46.35
1.19
2.23
39.71
500.00
3.91
180.00
46.13
46.22
46.27
1.26
2.15
39.59
200.00
46.12
46.16
46.23
1.26
2.16
39.54
240.00
45.76
45.80
45.87
1.17
2.14
39.58
260.00
45.32
45.43
45.47
1.14
2.09
39.64
300.00
44.40
44.48
44.50
1.27
2.01
39.56
360.00
44.72
44.82
44.87
1.50
2.07
39.49
400.00
46.08
46.18
46.23
1.48
2.08
39.23
440.00
45.69
45.81
45.93
1.43
1.88
39.01
480.00
43.67
43.80
43.92
1.51
1.68
38.11
500.00
42.93
43.03
43.15
1.51
1.71
37.42
